High Speed & Fiber Optic Connectors

  • CFP2
    CFP2
    Amphenol’s CFP2 (surface mount receptacle connector) is considered to be a candidate of future generation multi hundred Gbps systems. CFP2 is comprised of 104 position, 0.6mm pitch host and pluggable connectors. It is rated for 28 Gbps per channel with resonance dampening for improved signal integrity. The plug connector on the mating interface improves accuracy and aids in achieving high speed performance. The CFP2 interconnect system includes insert molding assemblies for top side contacts and press-fit cage assemblies complying with IEEE and ITU-T applications.
    Devamı
  • CFP4
    CFP4
    Amphenol’s CFP2 (surface mount receptacle connector) is considered to be a candidate of future generation multi hundred Gbps systems. CFP2 is comprised of 104 position, 0.6 mm pitch host and pluggable connectors. It is rated for 28 Gbps per channel with resonance dampening for improved signal integrity. The plug connector on the mating interface improves accuracy and aids in achieving high speed performance. The CFP2 interconnect system includes insert molding assemblies for top side contacts and press-fit cage assemblies complying with IEEE and ITU-T applications.
    Devamı
  • DDR4 Ultra Low Profile
    DDR4 Ultra Low Profile
    SPECIALLY DESIGNED SOCKETS FOR LOW PROFILE SYSTEM
    DDR4 Ultra Low Profile (ULP) vertical DIMM sockets provide 288 contacts on 0.85mm pitch and facilitate convenient memory expansion in servers, workstations, desktop PCs, and embedded applications in communications and industrial equipment.
    Ultra low module seating height of 1.1mm
    Lowest connector height of 13.1mm
    Reduced overall profile of the connector
    Compatible with standard DIMM module to help optimize airflow
    Low resistance contacts (registered DIMM) reduces power consumption in hardware
    Devamı
  • eQSFP
    eQSFP
    The eQSFP interconnect system is comprised of a 38 position 0.8 mm pitch SMT connector, and a press-fit cage. With four channels of data in one pluggable, the system interface is capable of transferring data up to 28 Gbps / Channel, and replacing up to 4 standard SFP+ receptacles. These features result in greater port density and overall cost savings over traditional SFP+ products. Supporting standards include, Gigabit Ethernet, InfiniBand, and SONET/SDH with different data rate options. eQSFP includes cages in single and ganged configurations with multiple heat sink options supporting various thermal requirements and port status with light pipes options.
    Devamı
  • ExpressPort QSFP
    ExpressPort QSFP
    The ExpressPort QSFP+/QSFP interconnect system and the stacked combos are comprised of 38-position 0.8mm pitch SMT connectors, as well as press-fit cages intended for external connections. Each port offers 4 channels which increases port density and contributes to cost savings. The ExpressPort QSFP+ E-Series connector family is rated at 28 Gbps per channel. It features as tamped and formed contact design providing improved mechanical durability, an integrated grounding structure,and resonance dampening features for superior crosstalk performance. The contact design is optimized for a smooth impedance profile resulting in improved SI performance.
    Devamı
  • ExpressPort SFP
    ExpressPort SFP
    Amphenol’s ExpressPort SFP+ 1xN connector, when combined with the ExpressPort SFP+ cage, provides data transfer speeds of up to 25 Gbps. This is the highest speed in the market for the SFP+ series. The design of the ExpressPort SFP+ connector minimizes impedance discontinuities and reflections at high data rates, and provides a 10 to 20 dB improvement in Near-End Cross talk. The connectors accept multiple transceivers per SFF-8431 and are compliant with SFF-8081 and SFF-8083 speci- fications. Our unique ExpressPort SFP+ cage features enhanced EMI shielding options in the form of metal spring fingers or elastomeric gaskets. Ganged versions are compliant with the SFF-8433 standard. The ExpressPort SFP+ 2xN combos consist of an integrated stacked connector system and a cage with compliant press-fit pins or solder tail.
    Devamı
  • MiniSAS
    MiniSAS
    The Mini-SAS external I/O connector system consists of a die-cast metal cage and a Compact Multi Lane SMT connector. The Mini-SAS can support Fiber Channel and Infini-Band standards, making it the perfect solution to the ever-growing demand of high-speed mass storage systems, servers, and storage area networks. Providing four serial send/receive channels per port, this connector system provides signal speeds of 6 Gbps per channel across the connector interface and is designed to satisfy the needs for gigabit serial data transmission applications. The connector satisfies the requirements of the INCITS T10 SAS 2.0 and SAS 2.1, and is also compliant with SFF-8086 and SFF-8088. The cage is mounted separately to the body so that the stress imposed by insertion and removal of the cable plug does not affect the signal/body solder joints. The connector is available with unique solder hold-down tabs designed to provide additional mechanical robustness in demanding applications.
    Devamı
  • MiniSAS HD
    MiniSAS HD
    The Mini-SAS High Density Interconnect is the next generation SAS system, with 4x, 8x and 16x cable-plugging options to provide faster data transmission and more bandwidth for end users. Our Mini-SAS HD is designed to be compliant with the SFF-8644 standard. It is also designed to save space with its increased density and reduced size as compared to the Mini-SAS 2.0. The Mini-SAS HD connector system has a 2-row, right angle connector with 12 Gbps per channel. Each connector handles 4 lanes of data for up to 48 Gbps of total bandwidth. Ganged options are also available up to a 1x4 configuration for up to 192 Gbps of total bandwidth. This connector will mate with active copper and optical cable assemblies, as well as active pluggable modules for extended-length applications in data centers. Main applications for Mini-SAS HD include HBA Servers, storage devices, and switches in data centers.
    Devamı
  • OSFP
    OSFP
    The OSFP interconnect system has 60 contacts per port and supports 16 high speed pairs. With a 0.6mm contact pitch, 4 rows of contacts and a horizontal port pitch of 23.38mm, the OSFP footprint is optimized for signal integrity performance. The stacked connector is enhanced for low crosstalk and has ground commoning for resonance dampening. It is also designed for 1U applications. An integrated heat sink for optimal thermal performance is a feature of the design.
    Devamı
  • PCIe M.2 Connector
    PCIe M.2 Connector
    HIGH PERFORMANCE SMALL CARD CONNECTOR
    Amphenol ICC's PCI Express® (PCIe) M.2 occupies less board space, offers more connector height options and supports higher data rates than PCIe® Mini Card connector. This makes it an ideal option for tablets, laptops and low profile storage/server applications.
    Devamı
  • RCx
    RCx
    RCx is a simple, high density, low cost, passive connector and cable system specifically designed for intra-rack connectivity of 25 Gb, 50 Gb and 100 Gb Ethernet allowing for a seamless intra-rack switch to adapter deployments. The streamlined design eliminates the need to include provision for active electrical components such as EEPROMs, optics, retimers, or management ICs. RCx is density optimized and can accommodate more than 128 25 G lanes in a RU faceplate. That leads two RCx2 receptables to fit on a half-height PCIe card faceplate or two Rcx4 to fit on a full-height PCIe card faceplate. Versatile, the 4-lane RCx4 receptacle can be used as a 4-lane port, or can be bifurcated to be used as multiple 2-lane and 1-lane ports.
    Devamı
  • SFP
    SFP
    The SFP interconnect system consists of a 20-position hot swappable I/O connector enclosed in a metal cage mounted to a host PCB. It is designed to support Gigabit Ethernet and Fiber Channel applications. The connector accepts multiple transceivers per INF-8074i and combines,transmits, and receives functions in a low cost, compact and flexible format. We offer a wide variety of cage configurations, which have a two-piece construction with enhanced transceiver mating tabs available in press-fit or solder tail versions. Stacked versions ( 2XN ) consist of a 2-row cage with integrated connectors. The entire assembly in press-fit pin compliant. Main applications of the SFP series include servers, storage, switches, and networking equipment.
    Devamı
  • UltraPort QSFP
    UltraPort QSFP
    The UltraPort QSFP+ interconnect system is comprised of a 38-position, 0.8mm pitch connector built for use in high speed serial applications. Each port offers 4 channels to increase port density which contributes to more board real estate and immense cost savings. The UltraPort QSFP+ connector supports next generation 100 G+ applications and transmits up to 32 Gbps per-serial-lane making it the fastest connector in the QSFP+ market. It features a stamped and formed contact design providing improved mechanical durability and resonance dampening features for superior performance. The design minimizes cross talk and transmission line impedance discontinuity across the connector interface at speeds up to 32 Gbps.
    Devamı
  • UltraPort SFP
    UltraPort SFP
    The UltraPortTM SFP+ interconnect system is comprised of a 20-position hot swappable I/O connector enclosed in a metal cage mounted to a host PCB. It supports 32Gbps applications with a backward compatibility for next generation Ethernet and Fibre Channel applications. Amphenol’s UltraPortTM SFP+ connector shares the same exceptional mating interface and EMI cage dimensions as the SFP+ form factor. The cages are built for use with several board thicknesses and assembly processes to accommodate server and switch applications with great cost savings. The connector accepts multiple transceivers per INF-8081 and combines, transmits, and receives functions in a low cost, compact and flexible format. We offer a wide variety of cage configurations, which have a two-piece construction with enhanced transceiver mating tabs available in press-fit or solder tail versions. Stacked versions (2XN) consist of a 2-row cage with integrated connectors. The entire assembly is press-fit pin compliant.
    Devamı
  • UltraPort SlimSAS
    UltraPort SlimSAS
    Amphenol’s SlimLine SAS system addresses various interconnect issues in next generation storage devices such as bulk cable form factor restrictions and the introduction of multi lane storage devices. The 8-row, 0.6 mm pitch, 24 Gbps per lane internal solution consumes the same area as the MiniSAS HD 4x solution targeted for next generation SAS-4. The proven high-speed connector and ribbon cable friendly design supports blade and mainstream server designs.
    Devamı
  • XCede IO
    XCede IO
    The XCede IO interconnect system is comprised of a 32 position, variable pitch connector built for use in high speed serial applications. Each port offers 4 channels to increase port density which contributes to more board real estate and immense cost savings. The XCede IO connector supports next generation 100 G+ applications and transmits up to 28 Gbps per-serial-lane. It features a stamped and formed contact design providing improved mechanical durability and resonance dampening features for superior performance. The design minimizes cross talk and transmission line impedance discontinuity across the connector interface at speeds up to 28 Gbps.
    Devamı
  • XFP
    XFP
    The XFP interconnect system is capable of a 10 Gbps data rate and is intended for external I/O connections. High speed serial interconnect applications include clusters, servers, and storage devices. Its single row cage configuration requires less space and is a lower cost alternative to parallel-optics VSR. XFP also requires less than one-third the power and physical space of an MSA interconnect with parallel interface. It has a single footprint for all links, and is hot-pluggable.
    Devamı
  • Singlemode Cable Assemblies
    Singlemode Cable Assemblies
    Amphenol is a premier manufacturer of singlemode patch cords in the telecommunications industry, meeting or exceeding many of the industry standard requirements for optical transmission loss, reflectance, visual endface specifications, and geometry.
    Devamı
  • ST Connectors and Cable Assemblies
    ST Connectors and Cable Assemblies
    Amphenol’s ST and STII connectors utilize a bayonet style mating concept to provide a secure, robust coupling mechanism. The enclosed spiral slotted coupling nut allows easy insertion in densely packed patch panels. The ST connector has been used extensively in telecom, data premise installation, and test lab applications. Special attention has been given to every ST performance parameter, increasing product repeatability and exceeding industry standards. The ST connector is available with a plastic or die cast body with a ceramic or stainless steel ferrule. Amphenol’s ST and STII connectors utilize a bayonet style mating concept to provide a secure, robust coupling mechanism. The enclosed spiral slotted coupling nut allows easy insertion in densely packed patch panels. The ST connector has been used extensively in telecom, data premise installation, and test lab applications. Special attention has been given to every ST performance parameter, increasing product repeatability and exceeding industry standards.
    Devamı
  • 1.2mm Cable Assemblies
    1.2mm Cable Assemblies
    Amphenol’s 1.2mm fiber optic assemblies are ideally suited for network applications where space in the fiber management trays is limited. The 1.2mm diameter of the cable reduces congestion in trays and racks, allowing for better airflow. These assemblies are a perfect complement to High Density fiber management systems.
    Devamı
  • Cassette Modules
    Cassette Modules
    Amphenol cassettes are available in LGX or High Density form factor and in a full range of fiber types: Singlemode, OM3 or OM4 Multimode. Amphenol cassettes are a factory assembled and fully tested rapid deployment accessory. No tools are required for installation. Amphenol's cassettes can accommodate up to 24 fibers per cassette, with a variety of adapter options front and rear.
    Devamı
  • HiD4 Cassette
    HiD4 Cassette
    The HiD4 is an industry leading high-density, miniature shelf mount cassette for passive applications such as splitters or CWDM MUX and DEMUX applications. The miniature HiD4 footprint provides full functionality with up to 14 front facing LC/APC or LC/UPC ports and its mounting is compatible with LGX® shelves. At approximately 3″ deep, and half the width of a single LGX module, this package provides significantly improved port density when compared with conventional LGX cassettes. The cassette’s unique housing design and increased port count available on the front faceplate of the device allows for port groupings by function, such as; commons and upgrades, wavelength channels and test/monitoring ports providing added versatility for the network architecture.
    Devamı
  • HiDT - Passive Tray-mount Module
    HiDT - Passive Tray-mount Module
    The HiDT has redefined the industry standard for compact splice tray mounted passive multi-component modules. HiDT tray modules are designed to integrate directly onto the All Systems Broadband Universal Splice/Component Tray (UST) with no intermediate mounting fixtures. The HiDT housing allows for up to 14 fiber ports, all exiting one end of the package. The innovative design of the HiDT housing offers improved port count and component capability creating design advantages for optical networks, while the small overall footprint allows for installation of two modules on a single splice tray, improving density in field deployment applications.
    Devamı
  • High Density Fiber Management
    High Density Fiber Management
    Amphenol HD Patch Panels provide a convenient point for patching and managing large number of fiber optic cables. The modular and high density design of the panels make them ideal in high density data center applications, for use in the main distribution area and horizontal and equipment distribution areas. The patch panels provide easy access to the cable assemblies, suitable cable routing features, and bend radius protection for the fibers.
    Devamı
  • LC Connectors and Cable Assemblies
    LC Connectors and Cable Assemblies
    Amphenol Fiber Optic Product's LC small form factor (SFF) connectors utilize the familiar RJ-45 latching mechanism. The LC provides great space savings in the network. With accelerated growth demanding greater bandwidth in less physical space, LC connectors have been established as the connector of choice for high density patch panels and installations.
    Devamı
  • LCX 1RU Fiber Patch Panel - 288-Port Patch Chassis
    LCX 1RU Fiber Patch Panel - 288-Port Patch Chassis
    Amphenol Telect designed LCX fiber splice panels and LCX fiber patch panels of various densities to suit network fiber splice, patching and routing requirements.

    Interconnection and cross-connection cabling from above or below enter at the two front corners of each LCX panel via isolation hooks and/or radius control arcs (sold separately) installed on-site to suit the application and entry/exit direction.

    Eight split arcs and 24 snap-in cable rings are standard with each panel. Amphenol Telect also offers optional kits (KIT-CMHOOK, KIT-CMRHOOK, KIT-CMARK) to satisfy cable management practices requiring multiple arcs or guide posts to separate and isolate groups of fiber cables.

    1RU models have densities up to 24 fiber terminations. Instead of front or rear doors, 1RU panels have a removable sliding drawer that can be extended at the front or rear of the chassis to maximize access to fiber connections.

    Pivoting arcs at corner entries and exits provide cable management. Entry and exit positions are compatible with entries and exits of other Amphenol Telect LCX panels.

    Prodcut Number: LCX-P281L
    Devamı
  • LC-X Flippable Cable Assembly
    LC-X Flippable Cable Assembly
    Amphenol’s LC-X flippable Uniboot connector simplifies cable routing in high density panels. The compact design allows for greater density as well as the convenience of reversing the polarity. Amphenol Uniboot LC-X flippable assemblies reduce congestion in racks and trays due to the one boot, one cable design that replaces the need for stocking two connectors of opposing polarities. With the new flippable technology, the polarity of the connector can be changed quickly without the use of special tools. In addition to this, the pitch can easily be changed from standard (6. 25mm) to mini (5. 25mm).
    Devamı
  • LCX Hinged 2RU - Hinged Patch Chassis Unloaded
    LCX Hinged 2RU - Hinged Patch Chassis Unloaded
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Amphenol Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H2RU
    Devamı
  • LCX Hinged 3RU Fiber Patch Panel
    LCX Hinged 3RU Fiber Patch Panel
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection. This is bulkhead-style fiber patching and splicing. With hinge benefits. Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately. Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard. Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network. Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture. Product Number: LCX-H3RU-00
    Devamı
  • LCX Hinged 3RU Fiber Patch Panel - 72-Port Angled, LC/UPC
    LCX Hinged 3RU Fiber Patch Panel - 72-Port Angled, LC/UPC
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H3RU-01
    Devamı
  • LCX Hinged 4RU - Hinged Patch Chassis Unloaded
    LCX Hinged 4RU - Hinged Patch Chassis Unloaded
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H4RU
    Devamı
  • LFD - Layered Fiber Demarcation Enclosure
    LFD - Layered Fiber Demarcation Enclosure
    The Layered Fiber Demarcation enclosure is designed for high-density fiber connectivity and splicing for indoor wall mount applications.

    This compact demarcation fiber enclosure can accommodate SC and LC style adapters and mass fusion splice sleeve holders or splice trays for single-fiber splice sleeves. Incorporated in a layered, split-housing design are separate carrier and customer areas with individual security bolts and padlock hasps. The flexible enclosure layout enables a variety of splicing and patching combinations as well as cable entrance/exit ports top and bottom. Click here to view a short video which shows how easy it is to store ribbon fiber in the Layered Fiber Demarc Box.
    Devamı
  • LGX Fiber Management
    LGX Fiber Management
    Amphenol’s 948 Series Rack Mount Patch Panels provide a convenient location for patching single mode or multimode fiber optic cables from the cable termination point to the lightwave equipment. They are available in a variety of sizes to accommodate from 24 to 96 fibers.

    The Rack Mount Patch Panels can be used in both cross-connect and interconnect applications. Preterminated multi-channel fiber optic pigtails are excellent for reducing installation costs and installer handling. The patch panel pigtail can be quickly and easily routed to the splicing location, eliminating the need for performing field terminations.

    Rack Mount Patch Panels are used in backbone intermediate and horizontal cross-connects, equipment rooms, building entrances, headends, central offices and computer rooms.
    Devamı
  • LTX - PATCH & STRANDED SPLICE PANEL - 24-PORT 1RU, SC/APC, PIGTAIL
    LTX - PATCH & STRANDED SPLICE PANEL - 24-PORT 1RU, SC/APC, PIGTAIL
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C241N-S
    Devamı
  • LTX 1RU Fiber Distribution Chassis
    LTX 1RU Fiber Distribution Chassis
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M1RU
    Devamı
  • LTX 1RU Patch & Stranded Splice Panels - 12-Port, SC/UPC, Pigtail
    LTX 1RU Patch & Stranded Splice Panels - 12-Port, SC/UPC, Pigtail
    The Amphenol Telect 1RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement. The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include: Circuit designation Latching doors Superior cable management Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack. Product Number: LTX-C121S-S
    Devamı
  • LTX 1RU Patch Only Panels - 12-Port, SC/UPC
    LTX 1RU Patch Only Panels - 12-Port, SC/UPC
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P121S
    Devamı
  • LTX 1RU Patch Only Panels - 24-Port, SC/APC
    LTX 1RU Patch Only Panels - 24-Port, SC/APC
    The Amphenol Telect 1RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P241N
    Devamı
  • LTX 1RU Patch Only Panels - 24-Port, SC/UPC
    LTX 1RU Patch Only Panels - 24-Port, SC/UPC
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P241S
    Devamı
  • LTX 2RU Fiber Distribution Chassis
    LTX 2RU Fiber Distribution Chassis
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M2RU
    Devamı
  • LTX 2RU Fiber Distribution Chassis - Black
    LTX 2RU Fiber Distribution Chassis - Black
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M2RU-BLK
    Devamı
  • LTX 2RU Patch Only - 72-Port, LC/UPC
    LTX 2RU Patch Only - 72-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P721L
    Devamı
  • LTX 2RU Patch Only Panels - 144-Port, LC/UPC
    LTX 2RU Patch Only Panels - 144-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141L-2RU
    Devamı
  • LTX 2RU Patch Only Panels - 48-Port, LC/UPC
    LTX 2RU Patch Only Panels - 48-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481L
    Devamı
  • LTX 2RU Patch Only Panels - 48-Port, SC/APC
    LTX 2RU Patch Only Panels - 48-Port, SC/APC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481N
    Devamı
  • LTX 2RU Patch Only Panels - 48-Port, SC/UPC
    LTX 2RU Patch Only Panels - 48-Port, SC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481S
    Devamı
  • LTX 2RU Patch Only Panels - 72-Port, SC/UPC
    LTX 2RU Patch Only Panels - 72-Port, SC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P721S
    Devamı
  • LTX 4RU Fiber Distribution Chassis
    LTX 4RU Fiber Distribution Chassis
    The Amphenol Telect 4RU bulkhead-style fiber-optic panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support most applications or requirements.

    Product Number: LTX-M4RU
    Devamı
  • LTX 4RU Fiber Distribution Chassis - Black
    LTX 4RU Fiber Distribution Chassis - Black
    The Amphenol Telect 4RU bulkhead-style fiber-optic panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support most applications or requirements.

    Product Number: LTX-M4RU-BLK
    Devamı
  • LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC
    LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:
    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141L-M
    Devamı
  • LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC, Pigtail
    LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141L-S
    Devamı
  • LTX 4RU Patch & Splice Panels - 144-Port, SC/APC
    LTX 4RU Patch & Splice Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141N-M
    Devamı
  • LTX 4RU Patch & Splice Panels - 288-Port, LC/UPC
    LTX 4RU Patch & Splice Panels - 288-Port, LC/UPC
    All Amphenol Telect LTX panels can also be configured for patch and splicing in a single chassis. Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option. A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution. Multifunctionality is accomplished in a single platform. Amphenol Telect LTX combination panels range from 1RU to 4RU, with capacities from 12 to 288 fibers.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C281L-M
    Devamı
  • LTX 4RU Patch & Stranded Splice Panels - 144-Port, LC/APC, Pigtail
    LTX 4RU Patch & Stranded Splice Panels - 144-Port, LC/APC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.
    Product Number: LTX-C141G-S
    Devamı
  • LTX 4RU Patch & Stranded Splice Panels - 144-Port, SC/APC
    LTX 4RU Patch & Stranded Splice Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141N-S
    Devamı
  • LTX 4RU Patch & Stranded Splice Panels - 288-Port, LC/UPC, Pigtail
    LTX 4RU Patch & Stranded Splice Panels - 288-Port, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C281L-S
    Devamı
  • LTX 4RU Patch Only Panels - 144-Port, LC/APC
    LTX 4RU Patch Only Panels - 144-Port, LC/APC
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P141G
    Devamı
  • LTX 4RU Patch Only Panels - 144-Port, LC/UPC
    LTX 4RU Patch Only Panels - 144-Port, LC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141L
    Devamı
  • LTX 4RU Patch Only Panels - 144-Port, SC/APC
    LTX 4RU Patch Only Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141N
    Devamı
  • LTX 4RU Patch Only Panels - 144-Port, SC/APC - Black
    LTX 4RU Patch Only Panels - 144-Port, SC/APC - Black
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141N-BLK
    Devamı
  • LTX 4RU Patch Only Panels - 144-Port, SC/UPC
    LTX 4RU Patch Only Panels - 144-Port, SC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141S
    Devamı
  • LTX 4RU Patch Only Panels - 288-Port, LC/UPC
    LTX 4RU Patch Only Panels - 288-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P281L
    Devamı
  • LTX CPRI Cable Management - 1RU, Cable Manager, Tray
    LTX CPRI Cable Management - 1RU, Cable Manager, Tray
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-1RU
    Devamı
  • LTX CPRI Cable Management - 2RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 2RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-2RU
    Devamı
  • LTX CPRI Cable Management - 3RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 3RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-3RU
    Devamı
  • LTX CPRI Cable Management - 4RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 4RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-4RU
    Devamı
  • LTX Patch & Splice Panels - 72-Port 2RU, LC/UPC, Pigtail
    LTX Patch & Splice Panels - 72-Port 2RU, LC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C721L-S
    Devamı
  • LTX Patch & Stranded Splice Panels - 24-Port 1RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 24-Port 1RU, SC/UPC, Pigtail
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C241S-S
    Devamı
  • LTX Patch & Stranded Splice Panels - 48-Port 2RU, LC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 48-Port 2RU, LC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C481L-S
    Devamı
  • LTX Patch & Stranded Splice Panels - 48-Port 2RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 48-Port 2RU, SC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C481S-S
    Devamı
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, LC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.
    Devamı
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/APC, Splice
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/APC, Splice
    The Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C961N-S
    Devamı
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Amphenol Telect: LTX-C961S-S
    Devamı
  • FC Connectors and Cable Assemblies
    FC Connectors and Cable Assemblies
    Amphenol’s FC connectors effectively terminate optical fiber in a variety of network applications. The connector is secured using a threaded coupling nut, providing a significant increase in pull-out performance. The FC connector also features an internal cavity and epoxy injection tube that virtually eliminates the possibility of improper epoxy application, thus providing higher manufacturing yields.
    Devamı
  • Indoor Adapters
    Indoor Adapters
    Amphenol Fiber Optic Products offers a complete range of indoor adapters that provide the perfect solution for high-density network needs. The one-piece adapter design is more durable than the typical two-piece design.
    Devamı
  • Indoor Stackable Adapters
    Indoor Stackable Adapters
    Amphenol’s stackable adapter system is an innovative way to aggregate a high number of connections into a small footprint. The stackable adapters are modular and allow network and equipment designers to improve fiber density for applications where it is required. The stackable adapters have a track system for alignment and a permanent locking feature that prevents the adapters from coming loose.

    Amphenol’s stackable adapter systems are for use with all IEC 61754-20 and TIA/EIA 604-10 compliant industry standard LC connectors and IEC 61754-7 and TIA/EIA 604-5 compliant industry standard MPO connector systems including MTP® branded connectors.

    The 45⁰ angled ear end adapters enable directional cable routing of LC/MPO assemblies. All Amphenol Stackable Adapters are offered with our patented internal shutter and external shutters as an option.

    Amphenol Fiber Optic Products will preassemble the stackable adapters into your custom configuration saving you time and ensuring the highest quality.
    Devamı
  • IPE Enclsoure Series
    IPE Enclsoure Series
    The Infinity Premises, IPE series enclosures were designed with the technician in mind. Completely reimagined using the real world needs for technicians and installers, the IPE series completes the Infinity Premises System, integrating installation hardware to work as a system. The QuicMount Rail allows passive and active devices to snap in without hardware. Cable Retention Slots allow installation to occur outside of the enclosure and simply slide into place. Continuous Bosses, modular accessories, weather and UV resistant materials are just a few more of the ground breaking innovations designed into the IPE Enclosure Series.
    Devamı
  • Loopbacks
    Loopbacks
    Loopback plugs are used for network diagnostics, system configuration testing, and device burn-in. Looping back the signal allows for testing of the optical network. MPO loopbacks are offered with 8, 12, and 24 fiber options in a compact footprint. Straight, crossed, or QSFP pin-outs are available. Loopbacks are available in multiple fiber types; LC and MPO loopbacks are offered with applicable fiber and polish type colored housings. Singlemode loopbacks are available with or without added attenuation.
    Devamı
  • MPO Connectors and Cable Assemblies
    MPO Connectors and Cable Assemblies
    Amphenol Fiber Optic Products manufactures a comprehensive line of MPO connectors and cable assemblies that provide high density connections for the expanding datacom market space.
    Devamı
  • Multimode Cable Assemblies
    Multimode Cable Assemblies
    Amphenol is a premier manufacturer of Multimode patch cords in the telecommunications industry, meeting or exceeding many of the industry standard requirements for optical transmission loss, reflectance, visual endface specifications, and geometry.
    Devamı
  • Node Cable Assembly
    Node Cable Assembly
    Amphenol’s node Cable Assemblies link optical transport cable to optical processing equipment. This connection is critical and requires an environmental seal between the cable and the node feed-thru. Amphenol’s node cables utilize a unique IP68 rated stainless steel feed-thru adapter, featuring an anti-twist coupling body and an optional anti-rotating nut. Our standard node assemblies use either a dielectric outside plant (OSP) cable or an armored OSP cable. Their multiple O-rings ensure a fully sealed cable and node.
    Devamı
  • Outdoor Enclosures
    Outdoor Enclosures
    Amphenol’s Fiber Demarcation Boxes offer superior protection for indoor or outdoor equipment installations. These sealed polymer enclosures provide a long life, weather resistant location to demarcate, combine, or segregate optical signal fibers for connection to various communication equipment, including backhaul, macro and small cell wireless applications. Enclosures are tailored with internal or external patching, splicing and/or distribution options to meet existing requirements and provision for future expansion.
    Entrance and exit ports can be configured to include pigtails, flexible port covers, sealing cable glands or pluggable receptacles for optical fiber cables. Provided with integrated mounting features, the enclosures are designed for easy installation in any location and environment, ideal for wall and pole mount applications.
    Devamı
  • Traceable Patch Cords
    Traceable Patch Cords
    Amphenol Fiber Optic Products presents an innovative solution for fiber patching. The traceable fiber patch cord is an effective solution for eliminating interconnect errors in dense interconnect environments. When the power source is connected to the traceable indicator on one end of the patch cord, the traceable indicator on the other end of the patch cord lights up, allowing identification of patches even in dense installations.
    Devamı
  • Wall Mount Panels
    Wall Mount Panels
    Wall Mount Distribution Panels are designed to be compact as well as provide ample fiber optic cable routing, organization and storage. The Wall Mount Distribution panels are designed for ease of installation with optional splice trays installed as well as optional pigtail cables.
    Devamı
  • SC Connectors and Cable Assemblies
    SC Connectors and Cable Assemblies
    Amphenol Fiber Optic Product's premier high-performance fiber optic SC connector utilizes a push/pull retention feature enabling easy insertion and removal, making it ideally suited for standard applications. The SC connector features an internal cavity and epoxy injection tube that virtually eliminates the possibility of improper epoxy application, thus providing higher manufacturing yields and superior quality.
    Devamı
İletişim Formu
Gönder
