High Speed & Fiber Optic Solutions Filtre

High Speed & Fiber Optic Connectors

  • 109 Series Connectors
    109 Series Connectors
    Hermaphroditic fiber optic connectors for deployable fiber optic communication requirements. These economical connectors are designed to be the industry's most rugged connector providing easy maintenance and superior optical performance. 109 series hermaphroditic connectors offers the ultimate in flexibility and is a direct replacement for the TAC4. The 109 connectors can function as either a plug or a receptacle to fit any system design. With these connectors, cable assemblies can be daisy-chained to provide the required distance for each specific deployment condition. The 109 connector line meets or exceeds the pertinent requirements of SMPTE standard 358M on harsh environment multi-channel fiber optic connectors suitable for deployment in demanding outdoor broadcast applications, including high definition television (HDTV) signal transmission.
    More
  • 711 Series, MIL-STD-1553B
    711 Series, MIL-STD-1553B
    711 Series is a range of connectors, couplers and terminators for MIL-STD-1553B databus applications. Available in both single and multiway housings the connectors feature a size 10 twinax contact offering higher density than standard connectors with 12 contacts available in a shell size 24 housing. Both in-line and connectorised transformer couplers are available with our unique can coupler design offering a fully encapsulated 10 STUB coupler system within a size 24 connector housing. Both BUS (77W) and STUB (3K) termination connectors and contacts are available and all items are flight qualified for use on military aircraft.
    More
  • ABS1696 / 1900 Elio Connectors
    ABS1696 / 1900 Elio Connectors
    The 1900ELIO series is derived from the legacy EN3545 connectors. Composite rectangular connectors offering 36 keying positions, it comes with 7 Elio® Optical termini for Aerospace applications.
    More
  • AquaLink FS140 Connectors
    AquaLink FS140 Connectors
    Amphenol FSI offers the AquaLink®, a cost-effective series of dry-mate submersible fiber optic connectors for underwater applications. The FS140 AquaLink® is designed for pressures up to 4,500 psi/300 bar (mated), which is adequate for 10,000 feet (3,000 meters) of water. The open mated receptacle supports pressures up to 450 psi. The standard AquaLink® supports up to four single mode or multimode fiber optic contacts with additional channels available upon request. Using precision ceramics, the AquaLink® provides excellent optical performance with insertion losses of 0.3dB typical and 0.75dB maximum. The AquaLink® is also easy to terminate, requiring standard fiber optic tools and training. The AquaLink® is offered in a variety of materials including stainless steel 316, Inconel 718 and marine bronze.
    More
  • ARINC 801 Connectors & Termini
    ARINC 801 Connectors & Termini
    Amphenol FSI offers fiber optic high performance termini and connector systems within a wide range of cylindrical and rectangular interconnect packaging. Amphenol offers ARINC 801 compliant termini for use in both cylindrical and rectangular connectors in commercial and military applications.
    More
  • AXOS Connectors
    AXOS Connectors
    The Amphenol AXOS fiber optic expanded beam is a miniature, hermaphroditic and cost-effective alternative to other expanded beam connectors, offering a robust and protected optical connection in a small size (OD 27 mm). This allows the user to establish a variable length daisy-chain link in both indoor and outdoor applications. The beam diameter makes the connection resistant to environmental contamination, temperature variations and humidity, while the design facilitates easy cleaning of the mechanical and optical connector parts.
    More
  • Board Level/Rectangular Fiber Optics
    Board Level/Rectangular Fiber Optics
    Amphenol is uniquely qualified to design and manufacture a wide range of rectangular connector products containing MIL-PRF-29504, HD20, MT Ferrule Fiber Optic Termini and ARINC 801 Termini.
    More
  • CTOS - Expanded Beam FO Connector
    CTOS - Expanded Beam FO Connector
    CTOS is an expanded beam fiber optic connector available in singlemode and multimode. Designed for gloved handling and blind mating in the most extreme conditions, features include: up to 4 channels, a hermaphroditic design, a protective window with contactless transmission and qualification in accordance to NATO/STANAG4290 norms.
    More
  • D38999 Type Fiber Optic Connectors
    D38999 Type Fiber Optic Connectors
    Amphenol offers a wide range of fiber optic interconnect solutions for use in the harsh environments found in military and aerospace applications. Amphenol Aerospace has established the rugged and reliable MIL-DTL-38999 as a common connector shell platform that houses a wide variety of fiber optic termini including MIL-PRF-29504 commercial equivalent, HDF20, ARINC 801, and MT ferrules. MIL-DTL-38999 Series III Tri-Start connectors are available in various insert arrangements, materials, and finishes to meet any type of environmental requirement. Our MIL-PRF-29504 style and HD20 termini can be combined with most of our copper contacts to create a large assortment of hybrid fiber/copper connector combinations.
    More
  • ECTA 133 Fiber Optic Push-Pull Connectors
    ECTA 133 Fiber Optic Push-Pull Connectors
    This connector is suitable for single- or multimode fiber optics. It uses E2000 couplers and can accept one or two optical fibers.
    More
  • EN4165 / SIM Elio for EN4531-101 Contacts
    EN4165 / SIM Elio for EN4531-101 Contacts
    Amphenol Air LB offers a wide range of optical modules fitted different standards of fiber optic termini or optical connectors. The module SIM Elio can be used with the whole range of EN4165 / SIM connectors.
    More
  • EN4165 / SIM for MPO Connectors
    EN4165 / SIM for MPO Connectors
    Amphenol Air LB offers a wide range of optical modules fitted different standards of fiber optic termini or optical connectors. The module SIM MPO can be used with the whole range of EN4165 / SIM connectors. MTP/MPO connector directly plugs and locks itself into the module. It can be easily removed for repair.
    More
  • EN4165 / SIM Luxcis for Arinc 801 Contacts
    EN4165 / SIM Luxcis for Arinc 801 Contacts
    Amphenol Air LB offers a wide range of optical modules fitted different standards of fiber optic termini or optical connectors. The module SIM Luxcis can be used with the whole range of EN4165 / SIM connectors.
    More
  • EN4165 / SIM with Module RJ45-Cat6a
    EN4165 / SIM with Module RJ45-Cat6a
    The Module RJ45-Cat6a can be used with the whole range of EN4165 / SIM connectors, for cable-to-cable or cable-to-PCB applications. Rear accessories are available to provide a sealed connection.
    More
  • EN4165 / SIMTac for MTAC Connectors
    EN4165 / SIMTac for MTAC Connectors
    Amphenol Air LB offers a wide range of optical modules fitted different standards of fiber optic termini or optical connectors. The module SIMTac can be used with the whole range of EN4165 / SIM connectors. MTAC connector directly plugs and locks itself into the module. It can be easily removed for repair.
    More
  • F-143
    F-143
    Amphenol Fiber Systems International (AFSI) manufactures a complete line of next generation circular fiber optic connectors designed to meet the needs of harsh environment applications. Building on the legacy of MIL-PRF-28876, Rev. E these connectors incorporate the latest technologies in fiber optic interconnect design. They are precision machined to stringent tolerances and designed to provide superior optical performance in extreme environmental conditions. The backshells feature the Quickloc™ captivation system developed by Amphenol Fiber Systems International. Not only is it simple to install, it is also easy to remove the captivated aramid yarn of the cable and recapture without cutting back the cable. The Quickloc™ backshell also allows easy access to maintain or reconfigure termini without altering the captivated aramid fiber.
    More
  • Fiber
    Fiber

    Fiber

    More
  • Fiber Optic Bulkhead Feedthrough
    Fiber Optic Bulkhead Feedthrough
    Amphenol extends its line of harsh environment fiber optic components with a multi-channel fiber optic feed-through. This feed-through is designed to perform in demanding aerospace environments and any other applications where a high degree of environmental sealing is required between bulkheads.
    More
  • Fiber-to-Antenna (FTTA) Connector Solutions
    Fiber-to-Antenna (FTTA) Connector Solutions
    Borne from the foundation of D38999 mil-spec harsh environment connectors, the FTTA interconnect solution combines standard fiber optic LC components and copper contacts in a rugged, affordable package.  The FTTA series is highly configurable to support a wide range of industrial applications where fiber and copper connectivity are required in a single connector for rapid deployment and easy maintainability.
    More
  • FS12 Pierside 12-Channel Fiber Optic Connector
    FS12 Pierside 12-Channel Fiber Optic Connector
    FS12 fiber optic connector is for harsh environment, broadcast and pierside applications. This connector is available in either single mode or multimode and uses field-proven MIL-PRF-29504 termini. The 12-channel FS12 Pierside connector design provides flexibility for current and future Navy communication requirements both afloat and ashore. This connector is also ideal for high fiber count tactical broadcast networks. Removable termini, qualified to MIL-PRF-29504 specifications, enable quick connector reconfiguration and field maintainability.
    More
  • FSHDM Series Hermaphroditic Duplex Miniature (HDM)
    FSHDM Series Hermaphroditic Duplex Miniature (HDM)
    The FSHDM (Hermaphroditic Duplex Miniature) is ideal for a variety of applications in Harsh Environments. FSHDM is hermaphroditic which allows the daisy chaining of cable assemblies, therefore eliminating the need for polarizing the assemblies or in-line adaptors. There is a bayonet locking mechanism, it is sealed, thus allowing high environmental and optical performance in a variety of applications ranging from land tactical to broadcasting applications. The FSHDM is offered in aluminium with hard black anodised finish, providing good anti corrosion properties and RoHs compliancy. The bayonet coupling offers simplistic and quick mating/demating. This connector series is compatible with tactical cable styles for the plug and simplex ruggedized cable for the receptacle both in multimode and singlemode.
    More
  • High Speed Board Level Connectors
    High Speed Board Level Connectors
    Amphenol Rectangular Board Level Connectors- Incorporate size 8 Quadrax or Differential Twinax contacts.
    More
  • JSFC15/16 Connectors + JSFC 17 & 18 Termini
    JSFC15/16 Connectors + JSFC 17 & 18 Termini
    Approved for use in JSF/F-35 applications. Based on Amphenol Composite Tri-Start, Qualified to MIL-DTL-38999.
    More
  • LC Field D38999-Type Connectors
    LC Field D38999-Type Connectors
    The patented RJStop® system allows use of a standard LC or LX5 patchcord in a metallic plug, which will protect it from shock, dust and fluids. There is no need for field termination. This metallic plug is connected into a receptacle, using a Tri-Start Thread coupling mechanism (MIL-DTL-38999 Series III type) with anti-decoupling device for high vibrations.
    More
  • Loopbacks - TFOCA
    Loopbacks - TFOCA
    Amphenol FSI has developed the Loopback TFOCA and TFOCA-II® plug configuration as an aid to system maintenance and troubleshooting of the tactical cable reels and systems that use them. The Loopback plugs come in a variety of configurations from 0 dB to -23dB to simulate a system operational condition. The use of the Loopback plug enables a technician to test a cable reel in the bi-directional mode by simply swapping leads on the test meter, thus saving considerable time and effort in establishing a systems operational status.
    More
  • LowPro Low Profile Fiber Optic Connectors
    LowPro Low Profile Fiber Optic Connectors
    Amphenol FSI offers the LowPro series of low-profile, fiber optic connectors. The FS115 LowPro has a height of 0.25" making it ideal for edge-card connections and other applications that require minimal connector profiles. Using field-proven M29504/14 & /15 termini, this fiber optic connector has excellent optical performance with insertion losses of 0.35 dB (typical), 0.75 dB (maximum) and typical back reflection of -50 dB (single mode). The standard connector is offered with two fiber optic channels. Additional channels are available upon consultation with the factory. The FS115 LowPro is available in side mount, panel mount and inline configurations to support multiple mounting options. LowPro connectors are also offered in a wide variety of plating options and materials (aluminum, stainless steel, marine bronze and brass) to satisfy a wide range of harsh environments.
    More
  • M28876 Fiber Optic Connectors
    M28876 Fiber Optic Connectors
    Complete line of circular fiber optic connectors designed and qualified to MIL-PRF-28876, Rev. E. These connectors are precision-machined to stringent tolerances and designed to provide superior optical performance in extreme environmental conditions. The backshells feature the QuickLoc captivation system developed by AFSI. Not only is it simple to install, it is also easy to remove the captivated aramid yarn of the cable and recapture without cutting back the cable. The QuickLoc backshell also allows easy access to maintain or reconfigure termini without altering the captivated aramid fiber.
    More
  • MFM Connectors
    MFM Connectors
    The Simplex MFM Fibre Optic range has been specifically designed to operate in Harsh Environments. The rugged, anti-vibration, corrosion resistant design ensures high environmental and optical performance in a variety of applications in the air, on land, and above / below sea.
    More
  • MIL-PRF-83526 TACBeam Connectors
    MIL-PRF-83526 TACBeam Connectors
    Amphenol FSI offers a MIL-DTL-83526/20 & /21 qualified expanded beam rugged fiber optic connector for military and industrial applications. Expanded beam technology expands and collimates the optical signal through the connector interface path resulting in a diameter many times that of the original beam. The optical beam is then refocused into the core of the receiving fiber. The larger beam diameter improves insertion loss performance in the presence of dust and debris. Also, because the lenses do not physically contact, there is no wear on the termini, which allows the connector to be mated and de-mated thousands of times without affecting optical performance.
    More
  • Mil-ST Connectors
    Mil-ST Connectors
    Amphenol FSI offers rugged military fiber optic ST connectors for deployable and fixed communication system requirements. AFSI's connectors are designed to provide the best possible optical performance in applications with severe environmental conditions. Various versions of connectors and adapters are available to meet a broad range of specific needs and system requirements. The M83522 connector is qualified for military applications and features a higher spring force than commercial ST connectors, allowing it to meet the shock requirements of MIL-C-83522. Commercial-Off-The-Shelf (COTS) ST connectors provide the same robustness with a spring force more consistent with commercial ST connectors, enabling them to connect effectively with other ST connectors and ancillary electronics.
    More
  • MT38999 Multi-Channel Connectors
    MT38999 Multi-Channel Connectors
    Amphenol offers a multi-channel circular connector with high density MT fiber optics. High fiber density in a relatively small circular connector package with all the advantages of the MIL-DTL-38999, Series III connector
    More
  • mTACh Miniature Fiber Optic Connector
    mTACh Miniature Fiber Optic Connector
    A high-performance, dual-channel hermaphroditic fiber optic connector, ideally suited for the energy, broadcast, and military markets. The mTACh connector is rugged, yet compact. It is designed for use in tight spaces yet durable enough for applications requiring multiple mating cycles and harsh environments. The connector design utilizes a simple termination procedure allowing users to terminate the connectors on site.
    More
  • MTRJ Field TV Connectors
    MTRJ Field TV Connectors
    The patented RJStop® system allows use of a standard MTRJ patchcord in a metallic plug which will protect it from shock, dust and fluids. There is no need for field termination. This metallic plug is connected into a receptacle, using a Tri-Start Thread coupling mechanism (MIL-DTL-38999 Series III type) with anti-decoupling device for high vibrations.
    More
  • NGCON Connectors
    NGCON Connectors
    MIL-PRF-64266 style fiber optic connectors with proven technology and features from existing connector standards of D38999 and 28876 for the next generation connector (NGCON). These innovative connectors include genderless contacts and high-density packaging.
    More
  • Optron Connectors
    Optron Connectors
    Amphenol FSI manufactures a complete line of circular hybrid connectors designed and qualified to MIL-PRF-28876, Rev. E. Optron connectors are precision-machined to stringent tolerances and designed to provide superior optical performance in extreme environmental conditions. The backshells feature the QuickLoc captivation system developed by AFSI, which is simple and easy to install by removing the captivated aramid yarn of the cable and recapture without cutting back the cable. The QuickLoc backshell also allows easy access to maintain or reconfigure termini without altering the captivated aramid fiber.
    More
  • Pegasus High Speed
    Pegasus High Speed
    PEGASUS High Speed brings an easy to use, lightweight, low-cost plastic circular connector to applications that have typically relied on heavier, more complicated, and more expensive, metal shell connectors. Supporting AS39029/90, /91, /113, /114 Twinax and ARINC600, ARINC404, AS39029/119, /120 Quadrax rear release, rear removable, size 8 style contacts, PEGASUS High Speed provides exceptional performance in tight spaces, with an efficient shell size 8(0.512”) outer diameter.
    More
  • Quadrax Fiber Optic Adapter Cavity Reducer
    Quadrax Fiber Optic Adapter Cavity Reducer
    Amphenol FSI offers an adapter or cavity reducer that resizes a size 8 Quadrax cavity to support an ARINC 801 fiber optic termini. This device allows the user to effortlessly convert electrical Quadrax contacts in rack and panel connectors (such as ARINC 404 and 600) to fiber optics without major redesign. The replacement of Quadrax with fiber optics provides higher data rates over longer distances, eliminates EMI/RFI and enhances security.
    More
  • Quadrax/Differential Twinax D38999 Connectors
    Quadrax/Differential Twinax D38999 Connectors
    Amphenol Connectors are ideally suited for the incorporation of shielded contacts for high performance interconnection applications. The circular family is built around MIL-DTL-38999 specifications, with Mil-approved and commercial styles offered.
    More
  • RJ
    RJ

    RJ

    More
  • Rugged Ethernet RJ45 Solutions
    Rugged Ethernet RJ45 Solutions
    Our Rugged RJ45 connectors offers a wide range of solutions, ranging from reverse bayonet, push-pull, bayonet, threaded and lever coupling configurations in both plastic and metal material, giving customers the flexibility of choosing the best solution for their application. All versions allow you to transform any RJ45 standard cordset into a rugged connector in 30 seconds, without tools.
    More
  • Rugged USB Memory Keys
    Rugged USB Memory Keys
    We provide reinforced USB memory keys, available in different capacities. They can only be used with our Amphenol Socapex USBFTV or USB3FTV series receptacles. When mated on the receptacle, the system is IP68 and allows data transmission in harsh environments.
    More
  • Solderless Coaxial PCB Edge Launch Connectors
    Solderless Coaxial PCB Edge Launch Connectors
    SV Microwave’s high-speed RF/coaxial solderless edge launch connectors are ideal for high frequency printed circuit board applications where precision is key. These rugged and durable interconnects are adjustable to accommodate multiple PCB thicknesses and do not cause damage to the printed circuit board. Current interface configurations include our high-frequency SMA, 2.92mm, 2.4mm and 1.85mm series.
    More
  • Space ST Connectors
    Space ST Connectors
    Amphenol FSI offers a fiber optic MIL-STD-83522 style connector and strain relief boot compliant to NASAEEE-INST-002 material guidelines for space applications. AFSI's Space ST connectors were tested to ASTME595 to evaluate the boot's out-gassing properties and are available for all of the popular fiber sizes. The Space ST is a M83522 style variant, which features a higher spring force than commercial ST connectors, allowing it to meet the shock and vibration requirements of MIL-C-83522. Stainless steel construction provides excellent mechanical strength and superior corrosion resistance. A companion adapter is available to support bulk head applications.
    More
  • Tactical High Density Fiber Optic Connectors
    Tactical High Density Fiber Optic Connectors
    Tactical High-Density (THD) connectors meet the ever-increasing demands of high-density harsh environment fiber optic connectivity. THD series connectors are particularly suited for the reliable tactical connections required for digital communication on and near the battlefield, high bandwidth commercial or industrial applications. AFSI's multi-channel fiber optic connectors are designed to provide the best possible optical performance for applications with extreme environmental conditions. The THD series is another example of AFSI's leadership in high-density tactical fiber optic connectors.
    More
  • TFOCA Multi-Channel Fiber Optic Connectors
    TFOCA Multi-Channel Fiber Optic Connectors
    The TFOCA connector is a hermaphroditic design utilized for tactical deployable communications systems. This genderless characteristic allows for concatenations of cable assemblies without regard for connector interface compatibility. The ruggedized connector and housing will withstand the repeated handling and mating cycles typically required for rapid fiber optic cable deployment and retrieval in a tactical environment.
    More
  • TFOCA-II 12-Channel Fiber Optic Connectors
    TFOCA-II 12-Channel Fiber Optic Connectors
    The TFOCA-II® 12-channel fiber optic connector, designed and patented by Amphenol Fiber Systems International (AFSI), is ideal for environmentally harsh conditions. This design takes advantage of the latest in fiber optic connectivity technology by utilizing industry standard physical contact ceramic ferrules. Although the TFOCA-II® connector is designed for minimal maintenance in the field, it can be fully field repaired reusing all components with the exception of the termini. Its removable end cap allows direct access to the alignment sleeve and termini.
    More
  • TFOCA-II 4-Channel Fiber Optic Connectors
    TFOCA-II 4-Channel Fiber Optic Connectors
    The heart of the TFOCA-II® family of deployable fiber optic connectors centers on the TFOCA-II® sealed free floating termini. The unique termini design enables TFOCA-II® connectors to seal against high humidity and moisture conditions while allowing full axial and orbital movement of the mated termini, providing low insertion loss and minimal back reflection. This unique connector series was designed and patented by AFSI for use in environmentally harsh conditions. The US Army has standardized on the 4-channel TFOCA-II® connector as the next generation fiber optic connector for military tactical deployable network applications.
    More
  • TFOCA-II® ProClean
    TFOCA-II® ProClean
    AFSI designed its patented TFOCA-II® hermaphroditic connector series to survive the harshest battlefield conditions imaginable. The sealed, free-floating termini design enables this series to survive high humidity and moisture conditions while allowing optimum alignment for low insertion loss and minimal back reflection.
    More
  • TFOCA-III Fiber Optic Connectors
    TFOCA-III Fiber Optic Connectors
    The TFOCA-III® series of 6 & 24-channel fiber optic connectors are ideal for environmentally harsh conditions. The TFOCA-III® design utilizes the latest technology in fiber optic connectivity by incorporating industry standard physical contact ceramic ferrules and alignment sleeves.
    More
  • TFOCA-XBT Connectors
    TFOCA-XBT Connectors
    AFSI’s TFOCA-XBT4™ incorporates expanded beam technology into the proven TFOCA-II® connector form factor. The TFOCA-II® physical contact connector is the standard fiber optic connector for the US Army, designed for and proven in the harshest of military and industrial applications. The TFOCA-XBT4™ is the next logical step, integrating expanded beam technology into the most popular harsh environment fiber optic connector in the world.
    More
  • Transition Adapters
    Transition Adapters
    Amphenol FSI offers a complete suite of passive fiber optic adapters to facilitate conversion from one network-based connector type to another. The small size of these adapters eliminates the need for bulky and expensive adapter cables. These adapters are available in single mode and multimode versions from one to four channels.
    More
  • TVµCom-10Gb+
    TVµCom-10Gb+
    The TVµCom-10Gb+ combines the 10 Gb/s Ethernet speed of the classic µCom-10Gb+ with the ruggedness of the 38999 Series III shell. TVµCom-10Gb+ exceeds 10Gb/s according to the IEEE 802.3an-2006, 10GBase-T standard, and the 38999 series III size 11 shell provides environmental resistance similar to MIL-DTL-38999 Series III. A reduced flange version is also available for Jam Nut receptacles to minimise the panel footprint.
    More
  • USB 2.0 Connectors
    USB 2.0 Connectors
    With USBFTVX, users can insert a standard USB 2.0 cordset into a metallic plug which will protect it from shock, dust and fluids. This range is for Atex Zone 2 environments. The metallic plug is connected into a receptacle, using a Tri Start thread coupling mechanism (MIL-DTL-38999 Series III type) with anti-decoupling device for high vibrations. USBFTVX features the same main characteristics as the USBFTV series
    More
  • USB 3.0 Connectors
    USB 3.0 Connectors
    With USB Field, users can insert a standard USB 3.0 cordset into a metallic plug which will protect it from shock, dust and fluids. No hazardous on-field cabling and grounding. Also available a version including plug + cordset. This metallic plug is connected into a receptacle, using a Tri Start Thread coupling mechanism (MIL-DTL-38999 Series III type) with an anti-decoupling device for high vibration.
    More
  • USB3F TV Reduced Flange
    USB3F TV Reduced Flange
    With USB field, you can insert a standard USB 3.0 cordset into a metallic plug which will protect it from shocks, dust and fluids. No hazardous on-field cabling and grounding!
    More
  • USB-B Solutions
    USB-B Solutions
    USB Field allows you to use a standard USB 2.0 connection in harsh environment
    More
  • CFP2
    CFP2
    Amphenol’s CFP2 (surface mount receptacle connector) is considered to be a candidate of future generation multi hundred Gbps systems. CFP2 is comprised of 104 position, 0.6mm pitch host and pluggable connectors. It is rated for 28 Gbps per channel with resonance dampening for improved signal integrity. The plug connector on the mating interface improves accuracy and aids in achieving high speed performance. The CFP2 interconnect system includes insert molding assemblies for top side contacts and press-fit cage assemblies complying with IEEE and ITU-T applications.
    More
  • CFP4
    CFP4
    Amphenol’s CFP2 (surface mount receptacle connector) is considered to be a candidate of future generation multi hundred Gbps systems. CFP2 is comprised of 104 position, 0.6 mm pitch host and pluggable connectors. It is rated for 28 Gbps per channel with resonance dampening for improved signal integrity. The plug connector on the mating interface improves accuracy and aids in achieving high speed performance. The CFP2 interconnect system includes insert molding assemblies for top side contacts and press-fit cage assemblies complying with IEEE and ITU-T applications.
    More
  • DDR4 Ultra Low Profile
    DDR4 Ultra Low Profile
    SPECIALLY DESIGNED SOCKETS FOR LOW PROFILE SYSTEM
    DDR4 Ultra Low Profile (ULP) vertical DIMM sockets provide 288 contacts on 0.85mm pitch and facilitate convenient memory expansion in servers, workstations, desktop PCs, and embedded applications in communications and industrial equipment.
    Ultra low module seating height of 1.1mm
    Lowest connector height of 13.1mm
    Reduced overall profile of the connector
    Compatible with standard DIMM module to help optimize airflow
    Low resistance contacts (registered DIMM) reduces power consumption in hardware
    More
  • eQSFP
    eQSFP
    The eQSFP interconnect system is comprised of a 38 position 0.8 mm pitch SMT connector, and a press-fit cage. With four channels of data in one pluggable, the system interface is capable of transferring data up to 28 Gbps / Channel, and replacing up to 4 standard SFP+ receptacles. These features result in greater port density and overall cost savings over traditional SFP+ products. Supporting standards include, Gigabit Ethernet, InfiniBand, and SONET/SDH with different data rate options. eQSFP includes cages in single and ganged configurations with multiple heat sink options supporting various thermal requirements and port status with light pipes options.
    More
  • ExpressPort QSFP
    ExpressPort QSFP
    The ExpressPort QSFP+/QSFP interconnect system and the stacked combos are comprised of 38-position 0.8mm pitch SMT connectors, as well as press-fit cages intended for external connections. Each port offers 4 channels which increases port density and contributes to cost savings. The ExpressPort QSFP+ E-Series connector family is rated at 28 Gbps per channel. It features as tamped and formed contact design providing improved mechanical durability, an integrated grounding structure,and resonance dampening features for superior crosstalk performance. The contact design is optimized for a smooth impedance profile resulting in improved SI performance.
    More
  • ExpressPort SFP
    ExpressPort SFP
    Amphenol’s ExpressPort SFP+ 1xN connector, when combined with the ExpressPort SFP+ cage, provides data transfer speeds of up to 25 Gbps. This is the highest speed in the market for the SFP+ series. The design of the ExpressPort SFP+ connector minimizes impedance discontinuities and reflections at high data rates, and provides a 10 to 20 dB improvement in Near-End Cross talk. The connectors accept multiple transceivers per SFF-8431 and are compliant with SFF-8081 and SFF-8083 speci- fications. Our unique ExpressPort SFP+ cage features enhanced EMI shielding options in the form of metal spring fingers or elastomeric gaskets. Ganged versions are compliant with the SFF-8433 standard. The ExpressPort SFP+ 2xN combos consist of an integrated stacked connector system and a cage with compliant press-fit pins or solder tail.
    More
  • MiniSAS
    MiniSAS
    The Mini-SAS external I/O connector system consists of a die-cast metal cage and a Compact Multi Lane SMT connector. The Mini-SAS can support Fiber Channel and Infini-Band standards, making it the perfect solution to the ever-growing demand of high-speed mass storage systems, servers, and storage area networks. Providing four serial send/receive channels per port, this connector system provides signal speeds of 6 Gbps per channel across the connector interface and is designed to satisfy the needs for gigabit serial data transmission applications. The connector satisfies the requirements of the INCITS T10 SAS 2.0 and SAS 2.1, and is also compliant with SFF-8086 and SFF-8088. The cage is mounted separately to the body so that the stress imposed by insertion and removal of the cable plug does not affect the signal/body solder joints. The connector is available with unique solder hold-down tabs designed to provide additional mechanical robustness in demanding applications.
    More
  • MiniSAS HD
    MiniSAS HD
    The Mini-SAS High Density Interconnect is the next generation SAS system, with 4x, 8x and 16x cable-plugging options to provide faster data transmission and more bandwidth for end users. Our Mini-SAS HD is designed to be compliant with the SFF-8644 standard. It is also designed to save space with its increased density and reduced size as compared to the Mini-SAS 2.0. The Mini-SAS HD connector system has a 2-row, right angle connector with 12 Gbps per channel. Each connector handles 4 lanes of data for up to 48 Gbps of total bandwidth. Ganged options are also available up to a 1x4 configuration for up to 192 Gbps of total bandwidth. This connector will mate with active copper and optical cable assemblies, as well as active pluggable modules for extended-length applications in data centers. Main applications for Mini-SAS HD include HBA Servers, storage devices, and switches in data centers.
    More
  • OSFP
    OSFP
    The OSFP interconnect system has 60 contacts per port and supports 16 high speed pairs. With a 0.6mm contact pitch, 4 rows of contacts and a horizontal port pitch of 23.38mm, the OSFP footprint is optimized for signal integrity performance. The stacked connector is enhanced for low crosstalk and has ground commoning for resonance dampening. It is also designed for 1U applications. An integrated heat sink for optimal thermal performance is a feature of the design.
    More
  • PCIe M.2 Connector
    PCIe M.2 Connector
    HIGH PERFORMANCE SMALL CARD CONNECTOR
    Amphenol ICC's PCI Express® (PCIe) M.2 occupies less board space, offers more connector height options and supports higher data rates than PCIe® Mini Card connector. This makes it an ideal option for tablets, laptops and low profile storage/server applications.
    More
  • RCx
    RCx
    RCx is a simple, high density, low cost, passive connector and cable system specifically designed for intra-rack connectivity of 25 Gb, 50 Gb and 100 Gb Ethernet allowing for a seamless intra-rack switch to adapter deployments. The streamlined design eliminates the need to include provision for active electrical components such as EEPROMs, optics, retimers, or management ICs. RCx is density optimized and can accommodate more than 128 25 G lanes in a RU faceplate. That leads two RCx2 receptables to fit on a half-height PCIe card faceplate or two Rcx4 to fit on a full-height PCIe card faceplate. Versatile, the 4-lane RCx4 receptacle can be used as a 4-lane port, or can be bifurcated to be used as multiple 2-lane and 1-lane ports.
    More
  • SFP
    SFP
    The SFP interconnect system consists of a 20-position hot swappable I/O connector enclosed in a metal cage mounted to a host PCB. It is designed to support Gigabit Ethernet and Fiber Channel applications. The connector accepts multiple transceivers per INF-8074i and combines,transmits, and receives functions in a low cost, compact and flexible format. We offer a wide variety of cage configurations, which have a two-piece construction with enhanced transceiver mating tabs available in press-fit or solder tail versions. Stacked versions ( 2XN ) consist of a 2-row cage with integrated connectors. The entire assembly in press-fit pin compliant. Main applications of the SFP series include servers, storage, switches, and networking equipment.
    More
  • UltraPort QSFP
    UltraPort QSFP
    The UltraPort QSFP+ interconnect system is comprised of a 38-position, 0.8mm pitch connector built for use in high speed serial applications. Each port offers 4 channels to increase port density which contributes to more board real estate and immense cost savings. The UltraPort QSFP+ connector supports next generation 100 G+ applications and transmits up to 32 Gbps per-serial-lane making it the fastest connector in the QSFP+ market. It features a stamped and formed contact design providing improved mechanical durability and resonance dampening features for superior performance. The design minimizes cross talk and transmission line impedance discontinuity across the connector interface at speeds up to 32 Gbps.
    More
  • UltraPort SFP
    UltraPort SFP
    The UltraPortTM SFP+ interconnect system is comprised of a 20-position hot swappable I/O connector enclosed in a metal cage mounted to a host PCB. It supports 32Gbps applications with a backward compatibility for next generation Ethernet and Fibre Channel applications. Amphenol’s UltraPortTM SFP+ connector shares the same exceptional mating interface and EMI cage dimensions as the SFP+ form factor. The cages are built for use with several board thicknesses and assembly processes to accommodate server and switch applications with great cost savings. The connector accepts multiple transceivers per INF-8081 and combines, transmits, and receives functions in a low cost, compact and flexible format. We offer a wide variety of cage configurations, which have a two-piece construction with enhanced transceiver mating tabs available in press-fit or solder tail versions. Stacked versions (2XN) consist of a 2-row cage with integrated connectors. The entire assembly is press-fit pin compliant.
    More
  • UltraPort SlimSAS
    UltraPort SlimSAS
    Amphenol’s SlimLine SAS system addresses various interconnect issues in next generation storage devices such as bulk cable form factor restrictions and the introduction of multi lane storage devices. The 8-row, 0.6 mm pitch, 24 Gbps per lane internal solution consumes the same area as the MiniSAS HD 4x solution targeted for next generation SAS-4. The proven high-speed connector and ribbon cable friendly design supports blade and mainstream server designs.
    More
  • XCede IO
    XCede IO
    The XCede IO interconnect system is comprised of a 32 position, variable pitch connector built for use in high speed serial applications. Each port offers 4 channels to increase port density which contributes to more board real estate and immense cost savings. The XCede IO connector supports next generation 100 G+ applications and transmits up to 28 Gbps per-serial-lane. It features a stamped and formed contact design providing improved mechanical durability and resonance dampening features for superior performance. The design minimizes cross talk and transmission line impedance discontinuity across the connector interface at speeds up to 28 Gbps.
    More
  • XFP
    XFP
    The XFP interconnect system is capable of a 10 Gbps data rate and is intended for external I/O connections. High speed serial interconnect applications include clusters, servers, and storage devices. Its single row cage configuration requires less space and is a lower cost alternative to parallel-optics VSR. XFP also requires less than one-third the power and physical space of an MSA interconnect with parallel interface. It has a single footprint for all links, and is hot-pluggable.
    More
  • AARC Cable Assembly
    AARC Cable Assembly
    Amphenol's harsh environment AARC plug and receptacle assemblies are available in 2-fiber or 4-fiber configurations. Based on the N-Type RF threaded connector housing, this interconnect system provides superior optical performance in outdoor environments using LC-style 1.25mm ceramic ferrules. The corrosion resistant metal housings provide a durable and environmentally protected solution for optical connectivity in areas exposed to elements such as rain, snow, dirt, and other types of contamination. Factory-terminated AARC assemblies are available in plug, receptacle, and in-line connector styles, and can be supplied as pigtails or jumpers in lengths starting from 1 meter. Factory-terminated AARC receptacle assemblies are available with flange, jam-nut, or in-line configurations. Amphenol’s AARC connectors are exceptionally suited for WiMax, LTE, 3G/4G/5G wireless, and base station applications.
    More
  • Direct Connect Solutions
    Direct Connect Solutions
    Amphenol direct connect trunk solutions offer fiber optic and/or power connectivity in a single cable, with up to 48 fiber pairs and 18 copper conductors available. A single trunk enables connectivity to several RRH’s without the need for a tower top distribution box. The direct connect hybrid trunk is the most efficient and easiest to install solution on the market. The plug and play installation system is the preferred choice of many communication equipment manufacturers and operators. A metal canister providing a secure and reliable hoisting and grounding mechanism splits power and optical cables into separate ruggedized short branches equipped with fiber optic outdoor harsh environment connectors and optional power connectors. The connection to the RRH is ensured with fiber jumpers factory terminated with RRH interface (large range available to fit most of RRH in the market) and optional power jumpers.
    More
  • IP-FX Housing
    IP-FX Housing
    The Amphenol IP-FX is a sealed, outdoor feedthru housing that is designed to provide dust and water protection for assemblies mating to outdoor enclosures and transmission equipment. The IP-FX is suitable to protect several connector types including LC Duplex, RJ45, USB, and others.

    The unique design of the IP-FX housing allows it to be supplied on factory terminated (tested cables) or field installed over existing cables such as LC Duplex or RJ45, making it an ideal solution for conversion from legacy systems to newer transmission equipment. IP-FX housing mates to equipment or enclosures that are pre-fitted with the FullAXS® -style receptacle, providing a water and dust sealed interface when mated. Applications include connection to Remote Radio Units (RRU/RRH), FTTA equipment and other outdoor systems.
    More
  • J-Connector Housing
    J-Connector Housing
    The Amphenol optical J-connector housing is designed for optical connectivity to outdoor installed electronics. Using a ‘Direct Connect’ topology, the J-Connector accepts either SFP or SFP+ pluggable transceivers, effectively transforming the passive optical assembly into an active, electrical interface. This connection method allows quick and easy replacement of the optics and allows re-configuration for upgrades.

    The field installable version can be installed over an existing outdoor simplex or duplex LC assembly for applications requiring on-site or local assembly manufacturing. The J-Connector optical bulkhead receptacle is designed to accept any MSA compliant SFP or SFP+ transceiver, providing both an IP67 grade water and dust ingress protection as well as grounding to the panel/cage for improved EMI shielding.
    More
  • PT-LC Cable Assembly
    PT-LC Cable Assembly
    Amphenol's harsh environment PT/LC plug assemblies and mating receptacles leverage the proven MIL-DTL-26482 spec connector system to provide an environmental seal and mechanical protection for 2 fiber duplex LC style connections. Available with either a quick-mate bayonet or anti-vibration threaded coupling, the PT/LC provides a simple and reliable sealed connection. Factory terminated PT/LC plug assemblies, in various lengths, can be provided as jumpers to connect with most any industry standard optical connectors, allowing hassle free integration with existing hardware. The PT/LC receptacle accepts standard simplex or duplex LC assemblies to provide cost effective connections to active devices or patching with LC pigtails or jumpers. The PT/LC is capable of performing in the toughest environments and is exceptionally suited for WiMax, LTE, 3G/4G/5G wireless, small cell and base station applications. Many available receptacle mounting configurations and cable types allow installation into almost any system or application.
    More
  • PT-MPO Cable Assembly
    PT-MPO Cable Assembly
    Amphenol harsh environment PT-MPO plug assemblies and mating receptacles leverage the proven MIL-DTL-26482 spec connector system to provide an environmental seal and mechanical protection for 4 to 24 fiber MPO style connections. The PT-MPO metal bayonet connector system is quick to deploy, requiring only ¼ turn. It is a metal construction and has a positive latching system (both audible and visual). Factory-terminated PT-MPO plug assemblies are available in lengths starting from 1 meter and can be provided as jumpers with breakouts to connect with most industry standard optical connectors, allowing hassle-free integration. The PT-MPO receptacle accepts industry standard MPO patch cables to be used inside the enclosure, allowing simple connection to QSFP devices, or can be used with a breakout cable for discrete single fiber or SFP connections. Amphenol’s PT-MPO connectors are exceptionally suited for WiMax, LTE, and other applications requiring more than 2 fibers. The PT-MPO is capable of performing in even the toughest environments.
    More
  • R2CT Housing
    R2CT Housing
    The R2CT field installable IP67 weatherproof housing is designed as a cost effective means of providing a removable interface for applications requiring protection from wet or dirty environments. It allows for quick and easy installation onto Optical LC, RJ45, or other outdoor communication assembly styles. The system can be field assembled over previously deployed assemblies or provided on factory terminated assemblies for quick and reliable deployments. The R2CT allows direct mating to edge mounted active devices or as a sealed feed-thru to adapters or internally mounted devices. The R2CT gland is also suitable for use as a feed-through interface for other type signal and fiber applications. Amphenol’s R2CT Field Installable cable glands are exceptionally suited for wireless base station applications.
    More
  • Singlemode Cable Assemblies
    Singlemode Cable Assemblies
    Amphenol is a premier manufacturer of singlemode patch cords in the telecommunications industry, meeting or exceeding many of the industry standard requirements for optical transmission loss, reflectance, visual endface specifications, and geometry.
    More
  • ST Connectors and Cable Assemblies
    ST Connectors and Cable Assemblies
    Amphenol’s ST and STII connectors utilize a bayonet style mating concept to provide a secure, robust coupling mechanism. The enclosed spiral slotted coupling nut allows easy insertion in densely packed patch panels. The ST connector has been used extensively in telecom, data premise installation, and test lab applications. Special attention has been given to every ST performance parameter, increasing product repeatability and exceeding industry standards. The ST connector is available with a plastic or die cast body with a ceramic or stainless steel ferrule. Amphenol’s ST and STII connectors utilize a bayonet style mating concept to provide a secure, robust coupling mechanism. The enclosed spiral slotted coupling nut allows easy insertion in densely packed patch panels. The ST connector has been used extensively in telecom, data premise installation, and test lab applications. Special attention has been given to every ST performance parameter, increasing product repeatability and exceeding industry standards.
    More
  • TxRx Cable Assembly
    TxRx Cable Assembly
    Amphenol's TxRx Harsh Environment Interconnect system is designed to provide an outdoor LC-based sealed connection to a board mounted SFP or RJ45 device within a sealed enclosure. The system is designed to provide IP67 dust and water protection when connector and receptacle are mated or with dust caps installed. Plug cap includes integrated pulling eye for easy installation. Amphenol’s TxRx assemblies are exceptionally suited for WiMax, LTE, wireless, wireless backhaul and base station applications.
    More
  • 1.2mm Cable Assemblies
    1.2mm Cable Assemblies
    Amphenol’s 1.2mm fiber optic assemblies are ideally suited for network applications where space in the fiber management trays is limited. The 1.2mm diameter of the cable reduces congestion in trays and racks, allowing for better airflow. These assemblies are a perfect complement to High Density fiber management systems.
    More
  • 4X InfiniBand
    4X InfiniBand
    High Speed Cables
    More
  • Cassette Modules
    Cassette Modules
    Amphenol cassettes are available in LGX or High Density form factor and in a full range of fiber types: Singlemode, OM3 or OM4 Multimode. Amphenol cassettes are a factory assembled and fully tested rapid deployment accessory. No tools are required for installation. Amphenol's cassettes can accommodate up to 24 fibers per cassette, with a variety of adapter options front and rear.
    More
  • CXP
    CXP
    The Amphenol CXP connectors come in a one-piece press-fit assembly system with twelve channels of up to 20 Gbps, resulting in 240 Gbps of total bandwidth. This allows our CXP to go beyond the 100 Gigabit Ethernet IEEE 802.3b,a and the InfinibandCXP12x QDR standards. The CXP series is the fastest and most dense I/O on the market today. It enables pluggable copper or optical cables to increase the flexibility of system level hardware for end users, and offers reduced cross-talk. The CXP interconnect system offers plug-to-receptacle containment with the various EMI gasket and EMI spring finger options, and is ideal for network switches, routers, servers and storage devices.
    More
  • HiD4 Cassette
    HiD4 Cassette
    The HiD4 is an industry leading high-density, miniature shelf mount cassette for passive applications such as splitters or CWDM MUX and DEMUX applications. The miniature HiD4 footprint provides full functionality with up to 14 front facing LC/APC or LC/UPC ports and its mounting is compatible with LGX® shelves. At approximately 3″ deep, and half the width of a single LGX module, this package provides significantly improved port density when compared with conventional LGX cassettes. The cassette’s unique housing design and increased port count available on the front faceplate of the device allows for port groupings by function, such as; commons and upgrades, wavelength channels and test/monitoring ports providing added versatility for the network architecture.
    More
  • HiDT - Passive Tray-mount Module
    HiDT - Passive Tray-mount Module
    The HiDT has redefined the industry standard for compact splice tray mounted passive multi-component modules. HiDT tray modules are designed to integrate directly onto the All Systems Broadband Universal Splice/Component Tray (UST) with no intermediate mounting fixtures. The HiDT housing allows for up to 14 fiber ports, all exiting one end of the package. The innovative design of the HiDT housing offers improved port count and component capability creating design advantages for optical networks, while the small overall footprint allows for installation of two modules on a single splice tray, improving density in field deployment applications.
    More
  • High Density Fiber Management
    High Density Fiber Management
    Amphenol HD Patch Panels provide a convenient point for patching and managing large number of fiber optic cables. The modular and high density design of the panels make them ideal in high density data center applications, for use in the main distribution area and horizontal and equipment distribution areas. The patch panels provide easy access to the cable assemblies, suitable cable routing features, and bend radius protection for the fibers.
    More
  • LC Connectors and Cable Assemblies
    LC Connectors and Cable Assemblies
    Amphenol Fiber Optic Product's LC small form factor (SFF) connectors utilize the familiar RJ-45 latching mechanism. The LC provides great space savings in the network. With accelerated growth demanding greater bandwidth in less physical space, LC connectors have been established as the connector of choice for high density patch panels and installations.
    More
  • LCX 1RU Fiber Patch Panel - 288-Port Patch Chassis
    LCX 1RU Fiber Patch Panel - 288-Port Patch Chassis
    Amphenol Telect designed LCX fiber splice panels and LCX fiber patch panels of various densities to suit network fiber splice, patching and routing requirements.

    Interconnection and cross-connection cabling from above or below enter at the two front corners of each LCX panel via isolation hooks and/or radius control arcs (sold separately) installed on-site to suit the application and entry/exit direction.

    Eight split arcs and 24 snap-in cable rings are standard with each panel. Amphenol Telect also offers optional kits (KIT-CMHOOK, KIT-CMRHOOK, KIT-CMARK) to satisfy cable management practices requiring multiple arcs or guide posts to separate and isolate groups of fiber cables.

    1RU models have densities up to 24 fiber terminations. Instead of front or rear doors, 1RU panels have a removable sliding drawer that can be extended at the front or rear of the chassis to maximize access to fiber connections.

    Pivoting arcs at corner entries and exits provide cable management. Entry and exit positions are compatible with entries and exits of other Amphenol Telect LCX panels.

    Prodcut Number: LCX-P281L
    More
  • LC-X Flippable Cable Assembly
    LC-X Flippable Cable Assembly
    Amphenol’s LC-X flippable Uniboot connector simplifies cable routing in high density panels. The compact design allows for greater density as well as the convenience of reversing the polarity. Amphenol Uniboot LC-X flippable assemblies reduce congestion in racks and trays due to the one boot, one cable design that replaces the need for stocking two connectors of opposing polarities. With the new flippable technology, the polarity of the connector can be changed quickly without the use of special tools. In addition to this, the pitch can easily be changed from standard (6. 25mm) to mini (5. 25mm).
    More
  • LCX Hinged 2RU - Hinged Patch Chassis Unloaded
    LCX Hinged 2RU - Hinged Patch Chassis Unloaded
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Amphenol Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H2RU
    More
  • LCX Hinged 3RU Fiber Patch Panel
    LCX Hinged 3RU Fiber Patch Panel
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection. This is bulkhead-style fiber patching and splicing. With hinge benefits. Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately. Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard. Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network. Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture. Product Number: LCX-H3RU-00
    More
  • LCX Hinged 3RU Fiber Patch Panel - 72-Port Angled, LC/UPC
    LCX Hinged 3RU Fiber Patch Panel - 72-Port Angled, LC/UPC
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H3RU-01
    More
  • LCX Hinged 4RU - Hinged Patch Chassis Unloaded
    LCX Hinged 4RU - Hinged Patch Chassis Unloaded
    Get fiber patching and splicing with hinge benefits. Swing the hinged LCX bulkhead either direction for flexibility in confined spaces; rely on the angled adapter plates' bend radius management and laser eye protection.

    This is bulkhead-style fiber patching and splicing. With hinge benefits.

    Now you can maneuver confined spaces in central offices, switches, or data centers while maintaining ultimate fiber protection. Install the hinged bulkhead to swing right or left— whichever direction your application requires. You'll have easy bulkhead access even in the tightest environments. You'll be ready to respond to build changes immediately.

    Rely on the panels' LGX®-compatible angled adapter plates for absolute bend radius management and advanced laser eye protection. Telect's industry-leading integrated cable management comes standard.

    Guaranteed for structural reliability and built to fit a standard footprint, LCX-H installs in any LGX®-compatible architecture. Scale the system to grow with your network.

    Choose LCX-H for every network to realize ultimate fiber protection, space efficiency, and a responsive architecture.

    Product Number: LCX-H4RU
    More
  • LFD - Layered Fiber Demarcation Enclosure
    LFD - Layered Fiber Demarcation Enclosure
    The Layered Fiber Demarcation enclosure is designed for high-density fiber connectivity and splicing for indoor wall mount applications.

    This compact demarcation fiber enclosure can accommodate SC and LC style adapters and mass fusion splice sleeve holders or splice trays for single-fiber splice sleeves. Incorporated in a layered, split-housing design are separate carrier and customer areas with individual security bolts and padlock hasps. The flexible enclosure layout enables a variety of splicing and patching combinations as well as cable entrance/exit ports top and bottom. Click here to view a short video which shows how easy it is to store ribbon fiber in the Layered Fiber Demarc Box.
    More
  • LGX Fiber Management
    LGX Fiber Management
    Amphenol’s 948 Series Rack Mount Patch Panels provide a convenient location for patching single mode or multimode fiber optic cables from the cable termination point to the lightwave equipment. They are available in a variety of sizes to accommodate from 24 to 96 fibers.

    The Rack Mount Patch Panels can be used in both cross-connect and interconnect applications. Preterminated multi-channel fiber optic pigtails are excellent for reducing installation costs and installer handling. The patch panel pigtail can be quickly and easily routed to the splicing location, eliminating the need for performing field terminations.

    Rack Mount Patch Panels are used in backbone intermediate and horizontal cross-connects, equipment rooms, building entrances, headends, central offices and computer rooms.
    More
  • LTX - PATCH & STRANDED SPLICE PANEL - 24-PORT 1RU, SC/APC, PIGTAIL
    LTX - PATCH & STRANDED SPLICE PANEL - 24-PORT 1RU, SC/APC, PIGTAIL
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C241N-S
    More
  • LTX 1RU Fiber Distribution Chassis
    LTX 1RU Fiber Distribution Chassis
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M1RU
    More
  • LTX 1RU Patch & Stranded Splice Panels - 12-Port, SC/UPC, Pigtail
    LTX 1RU Patch & Stranded Splice Panels - 12-Port, SC/UPC, Pigtail
    The Amphenol Telect 1RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement. The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include: Circuit designation Latching doors Superior cable management Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack. Product Number: LTX-C121S-S
    More
  • LTX 1RU Patch Only Panels - 12-Port, SC/UPC
    LTX 1RU Patch Only Panels - 12-Port, SC/UPC
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P121S
    More
  • LTX 1RU Patch Only Panels - 24-Port, SC/APC
    LTX 1RU Patch Only Panels - 24-Port, SC/APC
    The Amphenol Telect 1RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P241N
    More
  • LTX 1RU Patch Only Panels - 24-Port, SC/UPC
    LTX 1RU Patch Only Panels - 24-Port, SC/UPC
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P241S
    More
  • LTX 2RU Fiber Distribution Chassis
    LTX 2RU Fiber Distribution Chassis
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M2RU
    More
  • LTX 2RU Fiber Distribution Chassis - Black
    LTX 2RU Fiber Distribution Chassis - Black
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    Product Number: LTX-M2RU-BLK
    More
  • LTX 2RU Patch Only - 72-Port, LC/UPC
    LTX 2RU Patch Only - 72-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P721L
    More
  • LTX 2RU Patch Only Panels - 144-Port, LC/UPC
    LTX 2RU Patch Only Panels - 144-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141L-2RU
    More
  • LTX 2RU Patch Only Panels - 48-Port, LC/UPC
    LTX 2RU Patch Only Panels - 48-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481L
    More
  • LTX 2RU Patch Only Panels - 48-Port, SC/APC
    LTX 2RU Patch Only Panels - 48-Port, SC/APC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481N
    More
  • LTX 2RU Patch Only Panels - 48-Port, SC/UPC
    LTX 2RU Patch Only Panels - 48-Port, SC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P481S
    More
  • LTX 2RU Patch Only Panels - 72-Port, SC/UPC
    LTX 2RU Patch Only Panels - 72-Port, SC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P721S
    More
  • LTX 4RU Fiber Distribution Chassis
    LTX 4RU Fiber Distribution Chassis
    The Amphenol Telect 4RU bulkhead-style fiber-optic panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support most applications or requirements.

    Product Number: LTX-M4RU
    More
  • LTX 4RU Fiber Distribution Chassis - Black
    LTX 4RU Fiber Distribution Chassis - Black
    The Amphenol Telect 4RU bulkhead-style fiber-optic panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support most applications or requirements.

    Product Number: LTX-M4RU-BLK
    More
  • LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC
    LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:
    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141L-M
    More
  • LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC, Pigtail
    LTX 4RU Patch & Splice Panels - 144-Port, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141L-S
    More
  • LTX 4RU Patch & Splice Panels - 144-Port, SC/APC
    LTX 4RU Patch & Splice Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141N-M
    More
  • LTX 4RU Patch & Splice Panels - 288-Port, LC/UPC
    LTX 4RU Patch & Splice Panels - 288-Port, LC/UPC
    All Amphenol Telect LTX panels can also be configured for patch and splicing in a single chassis. Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option. A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution. Multifunctionality is accomplished in a single platform. Amphenol Telect LTX combination panels range from 1RU to 4RU, with capacities from 12 to 288 fibers.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C281L-M
    More
  • LTX 4RU Patch & Stranded Splice Panels - 144-Port, LC/APC, Pigtail
    LTX 4RU Patch & Stranded Splice Panels - 144-Port, LC/APC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Compact 1RU panels hold up to 36 fibers; 2RU panels handle 72 fibers; and 4RU panels hold 144 or 288 fiber splices, with a stranded or mass fusion splice cassette option.

    A combination patch and splice system increases versatility and provides a multifunctional platform for optical distribution.

    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.
    Product Number: LTX-C141G-S
    More
  • LTX 4RU Patch & Stranded Splice Panels - 144-Port, SC/APC
    LTX 4RU Patch & Stranded Splice Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C141N-S
    More
  • LTX 4RU Patch & Stranded Splice Panels - 288-Port, LC/UPC, Pigtail
    LTX 4RU Patch & Stranded Splice Panels - 288-Port, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-C281L-S
    More
  • LTX 4RU Patch Only Panels - 144-Port, LC/APC
    LTX 4RU Patch Only Panels - 144-Port, LC/APC
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-P141G
    More
  • LTX 4RU Patch Only Panels - 144-Port, LC/UPC
    LTX 4RU Patch Only Panels - 144-Port, LC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141L
    More
  • LTX 4RU Patch Only Panels - 144-Port, SC/APC
    LTX 4RU Patch Only Panels - 144-Port, SC/APC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141N
    More
  • LTX 4RU Patch Only Panels - 144-Port, SC/APC - Black
    LTX 4RU Patch Only Panels - 144-Port, SC/APC - Black
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141N-BLK
    More
  • LTX 4RU Patch Only Panels - 144-Port, SC/UPC
    LTX 4RU Patch Only Panels - 144-Port, SC/UPC
    The Amphenol Telect 4RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P141S
    More
  • LTX 4RU Patch Only Panels - 288-Port, LC/UPC
    LTX 4RU Patch Only Panels - 288-Port, LC/UPC
    The Amphenol Telect 2RU fiber-optic distribution panel offers a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels has key features for today’s network applications and requirements, fitting a variety of demarcation needs. They include:

    Circuit designation
    Latching doors
    Superior cable management
    Our LTX is designed to industry-standard form factor and can be mounted in any standard equipment rack.

    Product Number: LTX-P281L
    More
  • LTX CPRI Cable Management - 1RU, Cable Manager, Tray
    LTX CPRI Cable Management - 1RU, Cable Manager, Tray
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-1RU
    More
  • LTX CPRI Cable Management - 2RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 2RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-2RU
    More
  • LTX CPRI Cable Management - 3RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 3RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers.

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-3RU
    More
  • LTX CPRI Cable Management - 4RU, CBL MNGT, SPLTR, Traybased, 19"
    LTX CPRI Cable Management - 4RU, CBL MNGT, SPLTR, Traybased, 19"
    Integrated Cable Management with Cable management hooks included for routing individual fiber cables/jumpers

    Validating and debugging CPRI links between devices such as remote radio heads (RRH) and base band units (BBU) has become easier and less costly. The Amphenol Telect CPRI Interface Panels and Modules provide non-disruptive monitor ports to be installed between the Optical CPRI base band unit (BBU) and the remote radio head/active antenna, allowing Verizon Wireless cell operations and/or RF/System Performance Engineers to view and troubleshoot RF interference within the uplink Rx spectrum.

    Amphenol Telect provides color-coded couplers for the terminations and a designation label to title the uplink/radio unit (UL & RU), downlink/digital unit (DL & DU) and monitoring terminations.

    Amphenol Telect has color-coded fiber jumpers available in complete panel and module kits as well as in separate fiber jumper kits. Color codes are the standard blue, violet/pink, green, brown, yellow and white.

    Product Number: LTX-CMP-4RU
    More
  • LTX Patch & Splice Panels - 72-Port 2RU, LC/UPC, Pigtail
    LTX Patch & Splice Panels - 72-Port 2RU, LC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C721L-S
    More
  • LTX Patch & Stranded Splice Panels - 24-Port 1RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 24-Port 1RU, SC/UPC, Pigtail
    The Amphenol Telect 1RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C241S-S
    More
  • LTX Patch & Stranded Splice Panels - 48-Port 2RU, LC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 48-Port 2RU, LC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C481L-S
    More
  • LTX Patch & Stranded Splice Panels - 48-Port 2RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 48-Port 2RU, SC/UPC, Pigtail
    The Amphenol Telect 2RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C481S-S
    More
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, LC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, LC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.
    More
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/APC, Splice
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/APC, Splice
    The Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Product Number: LTX-C961N-S
    More
  • LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/UPC, Pigtail
    LTX Patch & Stranded Splice Panels - 96-Port 4RU, SC/UPC, Pigtail
    The Amphenol Telect 4RU fiber-optic distribution panels provide a cost-effective optical distribution point for patch-only applications, patch-and-splice needs, MPO/MTP conversions and splitter capabilities in an industry-standard footprint. Pre-loaded and unloaded panels are available to support virtually any application or requirement.

    The Amphenol Telect LTX line of bulkhead-style panels provide many features and capabilities that are key components for today’s network applications and requirements. Many of these features have been considered during development to fit a variety of demarcation needs. Features such as circuit designation, latching doors, and quality cable management add significant value to the panel. Many choices are available in the industry, so what makes the best bulkhead-style panel? For starters, choose a panel that features an industry-standard form factor and can be mounted in any standard equipment rack. A broad range of configuration options means that there will always be a panel available that fits the specific application. The Amphenol Telect LTX bulkhead fiber distribution panel will do just that. Below are some examples of terminations and densities available for those applications.

    Amphenol Telect: LTX-C961S-S
    More
  • FC Connectors and Cable Assemblies
    FC Connectors and Cable Assemblies
    Amphenol’s FC connectors effectively terminate optical fiber in a variety of network applications. The connector is secured using a threaded coupling nut, providing a significant increase in pull-out performance. The FC connector also features an internal cavity and epoxy injection tube that virtually eliminates the possibility of improper epoxy application, thus providing higher manufacturing yields.
    More
  • FDE - Fiber Demarcation Enclosure
    FDE - Fiber Demarcation Enclosure
    The Fiber Demarcation Enhanced Access enclosure is especially suited for Multiple Dwelling Unit (MDU) applications. When the FDE indoor wall-mount enclosure is combined with products such as our HiD4 passives, fiber pigtails, splice tray adapter kits, and grounding options, you have a ready-made solution for a multitude of applications.

    The Fiber Demarcation Enhanced Access enclosure has a low profile, side-by-side door design that provides an ideal environment for splicing and patching in indoor wall-mount applications. An integrated access door on the customer side of the enclosure provides a generous opening for a cleaning tool to reach the optical connectors resulting in a more craft-friendly design. The access door can be opened by-hand without the use of tools. This door is shown in the pictures below.
    More
  • FS3 - Fiber Splice Shelf
    FS3 - Fiber Splice Shelf
    The FS3 brings a new level of access, convenience, and security to fiber splicing applications. This shelf enables quick and easy fiber splicing and connectivity for rack mount applications. The adapter panel opening accommodates up to three single-width style LGX® modules or adapter plates. Cable termination brackets can hold cable diameters ranging from 0.25” to 0.50”. The design allows for expanded front accessibility with a removable top/front panel and sliding fiber management drawer with enhanced connector cleaning access, as well as rear access via a removable top/rear panel.
    More
  • Indoor Adapters
    Indoor Adapters
    Amphenol Fiber Optic Products offers a complete range of indoor adapters that provide the perfect solution for high-density network needs. The one-piece adapter design is more durable than the typical two-piece design.
    More
  • Indoor Stackable Adapters
    Indoor Stackable Adapters
    Amphenol’s stackable adapter system is an innovative way to aggregate a high number of connections into a small footprint. The stackable adapters are modular and allow network and equipment designers to improve fiber density for applications where it is required. The stackable adapters have a track system for alignment and a permanent locking feature that prevents the adapters from coming loose.

    Amphenol’s stackable adapter systems are for use with all IEC 61754-20 and TIA/EIA 604-10 compliant industry standard LC connectors and IEC 61754-7 and TIA/EIA 604-5 compliant industry standard MPO connector systems including MTP® branded connectors.

    The 45⁰ angled ear end adapters enable directional cable routing of LC/MPO assemblies. All Amphenol Stackable Adapters are offered with our patented internal shutter and external shutters as an option.

    Amphenol Fiber Optic Products will preassemble the stackable adapters into your custom configuration saving you time and ensuring the highest quality.
    More
  • IPE Enclsoure Series
    IPE Enclsoure Series
    The Infinity Premises, IPE series enclosures were designed with the technician in mind. Completely reimagined using the real world needs for technicians and installers, the IPE series completes the Infinity Premises System, integrating installation hardware to work as a system. The QuicMount Rail allows passive and active devices to snap in without hardware. Cable Retention Slots allow installation to occur outside of the enclosure and simply slide into place. Continuous Bosses, modular accessories, weather and UV resistant materials are just a few more of the ground breaking innovations designed into the IPE Enclosure Series.
    More
  • Loopbacks
    Loopbacks
    Loopback plugs are used for network diagnostics, system configuration testing, and device burn-in. Looping back the signal allows for testing of the optical network. MPO loopbacks are offered with 8, 12, and 24 fiber options in a compact footprint. Straight, crossed, or QSFP pin-outs are available. Loopbacks are available in multiple fiber types; LC and MPO loopbacks are offered with applicable fiber and polish type colored housings. Singlemode loopbacks are available with or without added attenuation.
    More
  • MPO Connectors and Cable Assemblies
    MPO Connectors and Cable Assemblies
    Amphenol Fiber Optic Products manufactures a comprehensive line of MPO connectors and cable assemblies that provide high density connections for the expanding datacom market space.
    More
  • Multimode Cable Assemblies
    Multimode Cable Assemblies
    Amphenol is a premier manufacturer of Multimode patch cords in the telecommunications industry, meeting or exceeding many of the industry standard requirements for optical transmission loss, reflectance, visual endface specifications, and geometry.
    More
  • Node Cable Assembly
    Node Cable Assembly
    Amphenol’s node Cable Assemblies link optical transport cable to optical processing equipment. This connection is critical and requires an environmental seal between the cable and the node feed-thru. Amphenol’s node cables utilize a unique IP68 rated stainless steel feed-thru adapter, featuring an anti-twist coupling body and an optional anti-rotating nut. Our standard node assemblies use either a dielectric outside plant (OSP) cable or an armored OSP cable. Their multiple O-rings ensure a fully sealed cable and node.
    More
  • Outdoor Enclosures
    Outdoor Enclosures
    Amphenol’s Fiber Demarcation Boxes offer superior protection for indoor or outdoor equipment installations. These sealed polymer enclosures provide a long life, weather resistant location to demarcate, combine, or segregate optical signal fibers for connection to various communication equipment, including backhaul, macro and small cell wireless applications. Enclosures are tailored with internal or external patching, splicing and/or distribution options to meet existing requirements and provision for future expansion.
    Entrance and exit ports can be configured to include pigtails, flexible port covers, sealing cable glands or pluggable receptacles for optical fiber cables. Provided with integrated mounting features, the enclosures are designed for easy installation in any location and environment, ideal for wall and pole mount applications.
    More
  • Traceable Patch Cords
    Traceable Patch Cords
    Amphenol Fiber Optic Products presents an innovative solution for fiber patching. The traceable fiber patch cord is an effective solution for eliminating interconnect errors in dense interconnect environments. When the power source is connected to the traceable indicator on one end of the patch cord, the traceable indicator on the other end of the patch cord lights up, allowing identification of patches even in dense installations.
    More
  • Wall Mount Panels
    Wall Mount Panels
    Wall Mount Distribution Panels are designed to be compact as well as provide ample fiber optic cable routing, organization and storage. The Wall Mount Distribution panels are designed for ease of installation with optional splice trays installed as well as optional pigtail cables.
    More
  • SC Connectors and Cable Assemblies
    SC Connectors and Cable Assemblies
    Amphenol Fiber Optic Product's premier high-performance fiber optic SC connector utilizes a push/pull retention feature enabling easy insertion and removal, making it ideally suited for standard applications. The SC connector features an internal cavity and epoxy injection tube that virtually eliminates the possibility of improper epoxy application, thus providing higher manufacturing yields and superior quality.
    More

Media Converters & Ethernet Switches

  • Analog-to-Digital Media Converters
    Analog-to-Digital Media Converters
    Amphenol Aerospace's High Speed Solutions offers a fully integrated standalone Analog-to-Digital Converter package.  Our integrated Analog-to-Digital Converters support input through High Frequency 50Ω MMCX RF type interconnects in a rugged MIL-DTL-38999 ultra-small form factor package. The analog inputs are single-ended and coupled to the latest in TI’s family of open architecture high speed ADC devices using a balun and AC coupling capacitor configuration to produce the broadband differential input required by the devices.
    More
  • Copper/Fiber Optic Media Converters
    Copper/Fiber Optic Media Converters
    Designed for harsh environments, our rugged Copper / Fiber Optic Media Converters give you the assurance of a continuous and secure data conversion. Custom configurations are available on demand.
    More
  • Copper-To-Fiber Digital Media Converters
    Copper-To-Fiber Digital Media Converters
    Amphenol Aerospace High Speed Solutions offers copper-to-fiber and fiber-to-copper media conversion with our hybrid integrated connectors. The family consists of protocol independent and Ethernet media conversion converters with more products being developed to meet our customers’ application needs.
    More
  • Ethernet Switches
    Ethernet Switches
    Designed for harsh environments, our Rugged Ethernet Switches give you the assurance of a continuous and secure data transmission between all your communication equipment.
    More
Contact Form
Send
