This device is aimed to applications that need on-field arbitrary initial and final travel reference points calibration. Once these have been set, the A15-3P provides accurate position feedback output to the controller.

Designed to be a cost-effective replacement for absolute encoders, the A15-3P series offers an SMD, Vertical and Through Hole mount solution for the majority of Position/Angle Rotary Sensor and multi-purpose control applications such as garage door oppeners, gauges, rotary actuators and robotics.

Thermometrics A-1996 HVAC Duct Temperature Sensor offers OEM solutions for measuring the temperature of air in ventilation ducts. The temperature reading is wired to a control module, where the system compares the temperature reading to a temperature set-point and adjusts outputs accordingly.

The NovaSensor P330 Series of Absolute Pressure Sensor Die, or piezoresistive pressure die, offers the same superior stability and sensitivity as in larger chips, but in an extremely small footprint for invasive applications where small size is critical. It has excellent measurement accuracy, which is ideal for demanding applications with restricted dimensional profiles such as medical catheters and IC packages. NovaSensor’s proprietary SenStable® process provides excellent long term stability and repeatability.

The Accusolve Diesel Particulate Filter (DPF) Soot Sensor utilizes radio frequency technology to enable accurate measurement of accumulated soot in the DPF, providing real-time soot loading data and real time closed loop control of the DPF regeneration process. Accurate measurement of the soot load allows for the optimization and reduction of regeneration cycles of the DPF. This in turn allows for improved fuel economy and improved filter life for active and passive regeneration systems.

The Active In Car Temperature Sensor provides in-cabin temperature measurement for vehicles that have an automated temperature control system to improve temperature accuracy, cabin comfort and efficiency of the vehicle's temperature control system.

SGX Sensortech offer a range electrochemical toxic gas sensors designed for the measurement of atmospheric toxic gases, Carbon monoxide, Hydrogen sulphide, Ammonia, Nitrogen Dioxide and many more. The sensors are designed specifically for portable or fixed instrumentation for use within the Mining, Automation and control, Industrial health and safety, Oil and gas and utilities.

The AAS-AQS-UNO Engineering Evaluation Board is used to evaluate the Telaire air quality sensors. It can support T9602 temperature and humidity sensors, T6713 carbon dioxide sensors, SM-PWM-01C dust sensors and other sensors from the Amphenol range. Moreover, the OLED display and Bluetooth output can be supported at the same time. This evaluation board is designed to speed up evaluation and development of the relevant sensors. The serial output can be configured to send sensor data to a PC over the USB connection for recording and analysis in 3rd party software.

Airbags have been designed to help protect adults in a moderate to severe frontal collision. To do this, the passenger’s front airbag is quite large, and it can inflate with enough force to cause very serious injuries. There are conditions where the automatic shut off feature will not completely insure safety (seat too far forward, small child in a car seat), there could be a need to manually disarm the passeger sode airbag.

Even though the vehicle may include an advanced front airbag system that automatically turns the passenger’s front airbag off, all manufacturers offer a manual cutoff system for an additional measure of safety. These manual systems are typically activated or deactivated by turning them using the vehicle´s ignition key.

This rotary switch seamlessly adapts to these systems and reliably actuates the transition between the “on” and “off” states.

The Ambient Air Temperature Sensor measures the temperature outside the passenger compartment and is usually mounted inside or near the front bumper. The sensor provides input to automatic HVAC systems to help control the interior temperature of the automobile. The sensor also provides the vehicle occupants with temperature readings from outside the car. This information is particularly useful when driving under near freezing or freezing conditions.

The right moisture meter makes all the difference when surveying, cleaning or restoring a property after water damage! The Protimeter Aquant (non-invasive) is the sister product to the Surveymaster and helps you locate moisture quickly in a wide range of materials with a RF measurement system unique to the Protimeter. This system allows you to detect moisture up to ¾” (20mm) below and behind the surface in the most efficient way possible.

All Protimeter instruments have a two-year warranty.

The NovaSensor P1905 Backside Absolute Pressure Sensor Die is a piezoresistive sensor die designed for absolute pressure measurements in aggressive (harsh) media. The die has a reference vacuum chamber formed by hermetic low-stress bonding of silicon cap to the top side of device wafer. By applying pressure from backside of the die, P1905sensor die eliminates the direct contact of sensor circuitry on top side with the applied media, which allows the P1905 die to measure pressure in aggressive liquids and gases. With NovaSensor’s SenStable® process, P1905 die features excellent long-term stability and repeatability (< 0.1% / year typ.).

The Battery Pack Temperature Sensor is a ring terminal temperature sensor that measures surface temperature. It is important to monitor the temperature on hybrid batteries for overcharging protection, as well as to optimize battery performance.

MA100 | MA200 | MA300
The Thermometrics NTC Type MA Series of Biomedial Chip Thermistors is designed for use in applications involving both intermittent and continuous patient temperature monitoring with range of 32°F to 122°F (0°C to 50°C). Although low in cost, these highly stable, precision thermochips provide the reliability, tight interchangeable tolerances, geometries and fast response times that are often required in biomedical applications.

SGX Sensortech offer a large range of pellistor component and Explosion proof certified flammable and thermal conductivity gas sensors designed for the measurement of atmospheric flammable gases. The sensors are designed specifically for fixed instrumentation for OEM use within the Mining, Automation and control, Industrial health and safety, Oil and gas and utilities. These sensors are required to be fitted within OEM certified Explosion proof certified housings or SGX versions are available.

Advanced Sensors is excited to announce the release of a new generation of Telaire CO2 transmitters targeting indoor air quality and energy conservation applications.

The Ventostat® T8031 duct mount CO2 transmitter offers accuracy and versatility at an affordable price. This exceptional product line touts an unobtrusive form factor that is easy to install, simple to use, and remains accurate over the expected life of the device using Telaire’s patented ABC Logic™ (Automatic Background Calibration) technology.

The Telaire Ventostat T8041 CO2 Duct Probe Transmitter is suitable for indoor air quality and energy conservation applications, offering accuracy and versatility at an affordable price. This exceptional product line touts an unobtrusive form factor that is easy to install, simple to use, and remains accurate over the expected life of the device using Telaire’s patented ABC Logic™ (Automatic Background Calibration) technology.

The Telaire Ventostat T8042 CO2 Duct Probe Transmitter is suitable for indoor air quality and energy conservation applications, offering accuracy and versatility at an affordable price. This exceptional product line touts an unobtrusive form factor that is easy to install, simple to use, and remains accurate over the expected life of the device using Telaire’s patented ABC Logic™ (Automatic Background Calibration) technology.

The Telaire T3000 Series is a range of sensors designed to meet the specific needs of customers who require measuring Carbon Dioxide in harsh or difficult environments. Based on a series of modules the casing offers a number of combinations to meet the needs of range, supply voltage, and output type in a range of applications. Example applications include incubators, buses, refrigerators, subway stations, and railway carriages.

The Coolant Temperature Sensor (CTS) monitors the temperature of the coolant that is being pumped around the battery to cool the battery module of EV/PHEVs. If the battery module starts to overheat, the Coolant Temperature Sensor relays a signal to the Battery Management System (BMS). The BMS uses this information to prevent battery packs from any damage and maximize the performance.

The Thermometrics NTC Type RL of Cryogenics Thermistor Probes are designed for use in the range of 25°C/77°F (room temperature) to -196°C/-320.8°F (the boiling point of Liquid Nitrogen).
Cryogenic thermistor probes consist of a pressed disc thermistor attached to #27 AWG silver lead wires. These units are very stable, exhibit no hysteresis effects,and rapid temperature cycling from 77°F to -320.8°F (25°C to -196°C) has no measurable effect on electrical, thermal or mechanical properties. These units are well suited for Cryogenic control applications such as liquid level in the 77°F to -320.8°F (25°C to -196°C) range. They may be used at temperatures below the Nitrogen Point with suitable instrumentation.

One of our core competences has always been the high experience in manufacturing custom sensors and controls according to customers´ requirements, coping with even the hasher environments´ conditions using rotary, linear and multiturn contact and non-contact technologies. The pursuit of the most cost-effective total custom-engineered Sensors Solution for your needs is firmly embedded in our business philosophy, whatever your requirements may be, from adapting standard products to complete new designs. Rapid prototyping, low batches accepted, up to 360º measuring range, analog, PWM, SPI, switch outputs are some of the key features offered by Piher. We offer accurate and reliable 360° non-contact angular position sensing.

The Cylinder Head Temperature Sensor is designed to take the place of one of the cylinder head bolts on a diesel engine. The sensor’s purpose is to measure the cylinder head temperature and to signal the vehicle’s operator if an engine overheats (that is, if an engine over-temperature is taking place). The engine will be in danger of permanent damage if it continues to run at an elevated temperature.

The combination of the well-known PT15/PTC15/PS15 control potentiometers with a Detent Control Mechanism (DCM) affords the appliance designer the possibility to solder the potentiometer onto the Control PCB assembly and then, in a second operation, assemble the DCM over it. This removes the need to build Detents into the User front panel of the appliance, simplifying, and significantly reducing the total cost of the solution.

The detent torque can be modified according to Customer requirements (depending on the input dial’s diameter, etc) as can the number and position of the detents.

Fully customiseable detented potentiometer that features:

-detents (or no detents)
-end stops
-plastic / metal shafts
-"plug-and-play" connectors
-"push to turn" function
-availability as switch, encoder or potentiometer

The Modus T Series of Differential Pressure Transmitters measure low pressures and feature low power consumption with a variety of analog signal outputs. A wide selection of standard pressure ranges and electrical ratings is available. These transmitters feature: no moving parts to wear out, reliable long term stability, and are virtually position insensitive.

The Series T transmitters are an excellent choice for many HVAC, process and automation monitoring requirements. These transmitters monitor: filter differential pressures, fan static pressures, clean room pressures, variable air volume systems and velocity pressures. They have been used for bubbler level systems, leak detection and in medical and analytical instruments.

The transmitters are housed in a flame retardant, glass-reinforced polyphenylene oxide (NORYL(tm)) case. Electrical connections are made by means of a 3/8" terminal strip with #6 screws.

The Series T includes four models: Model T10, Model T20, Model T30 and Model T40. These four models incorporate a variety of power and signal options.

The span or zero adjustment is performed with a 20-turn potentiometer for fine resolution.

Moisture damage prevention begins with a better diagnosis.

The Digital Mini allows building professionals—such as flood damage restoration contractors, surveyors, homebuilders and architects—to assess building moisture levels during new build and refurbishing activities. It helps you easily identify the extent of the moisture penetration, diagnose the cause of the problem and monitor changes in moisture level. Plus, the ability to add optional attachments and a patent pending reference mode enables you to compare your reading with a baseline measurement.

The NovaSensor NPA-201 Digital Output Absolute Pressure Sensor provides low power consumption and compact size, making it ideal for battery-powered and mobile applications or any application where size is a constraint. In today’s growing market for portable electronics and wearables with multiple parameters being measured there are many applications that require an accurate measurement of barometric pressure to determine factors such as altitude.

Thermometrics Discharge Air Temperature Sensor (DAT) is used to measure the temperature of the air that is emitted from a vehicle's air ducts. This temperature reading is fed back to the control module, and the system compares this temperature reading to what the occupant of the vehicle has the temperature set at on the air conditioning system. The control module calculates the temperature delta and automatically adjusts the HVAC system to minimize this temperature difference.

Our most popular instruments in 3 new convenient cases:

BLD7714-SM
Hygromaster 2 and Surveymaster Kit in thermoformed case Thermoformed case, deep wall probes and heavy duty moisture probe.

BLD7714-DM
Hygromaster 2 and Digital Mini Kit in thermoformed case Thermoformed case and moisture probe.

BLD7714-AQ
Hygromaster 2 and Aquant Kit in thermoformed case Thermoformed case.

By Amphenol Advanced Sensors | Protimeter

The Dual Solar Sensor uses two photo diode cells to measure the intensity of the light that enters into the cabin of the vehicle. It then takes this information and feeds it back to the automatic temperature control (ATC) unit of the vehicle's air conditioning system. The air temperatures of the driver's side and passenger side are then automatically adjusted up or down depending upon the amount of light entering both sides of the vehicle. The sensor is mounted on the IP panel near the vehicle's front window.

The extended temperature range (-40ºC to +120ºC) allows this encoder to be employed in extreme environmental applications where other encoders currently on the market can not be used. This in combination with optional SMD or through-hole mounting makes the E-15 series ideal for automotive heating, ventilation & air conditioning, oven & microwave (white and brown goods in general), kitchen appliance and power tools.

SGX has a proprietary MOS technology utilizing state of the art MEMS technology, combining a specialized nano-particle sensing layer with a patented poly-silicon heater. This unique design creates a highly sensitive and responsive semiconductor sensor, manufactured on an automotive production line for outstanding quality and performance. These sensors are easily capable to detect and measure combustible and pollution gasses in parts per billion (PPB) and are suitable for many environmental, automotive and industrial applications worldwide.

The E-stat Controller is used in automobile air conditions to prevent the evaporator core from freezing. The NTC probe senses the temperature of the air as it passes through the evaporator core. An electronic control circuit interprets the change in resistance of the thermistor to indicate when the evaporator core is near freezing. The control circuit then provides an output to disengage the compressor clutch, allowing the evaporator core to warm. When the air temperature of the evaporator core warms up, the circuit reactivates the clutch allowing the evaporator to cool.

Thermometrics Evaporator Core Temperature Sensor measures evaporator core temperature in a vehicle's HVAC system so that it doesn’t freeze over, preventing a costly repair. The ultra fast response time aids in the HVAC system efficiency by enabling the evaporator core to operate closer to 0°C without the risk of a freeze over condition.

Thermometrics Evaporator Temperature Sensor is used to measure evaporator core temperature. An evaporator cools the refrigerant in the HVAC system. Since the evaporator core operates at temperatures very close to 0°C, it is important to have an accurate and robust thermistor to measure its temperature to prevent the core from freezing. A frozen core could result in costly damage to the evaporator core and diminished HVAC operation, so that the cabin temperature can no longer be controlled.

Thermometrics Exhaust Gas High Temperature Sensor operates over a temperature range from -40°C to 850°C. It monitors the temperature before and after SCR system in vehicle engines as part of the engine control strategy. It is designed for fast response, optimized for thermal dissipation and suitable for high vibration and corrosive environments.

The Thermometrics NTC Type FP Series of Fastip Thermistor Probes are ideally suited for high speed measurement and control of fluid temperatures, fluid level or flow. They offer the ease of handling associated with large glass probe thermistors, as well as the ultra-fast response times of small glass-coated bead thermistors.

Thermometrics Fuel Temperature Sensor (FTS) is designed to measure the temperature of a vehicle's fuel and relay this information to the engine control unit, so that it can optimize the air-to-fuel mix ratio, depending on what the fuel temperature is with respect to the intake air temperature. The sensor enables the vehicle to run at maximum efficiency based on temperature. The more optimized the combustion process is, the less pollutants that are emitted via the exhaust system.

The Thermometrics MA400X Series of Fully Autoclavable Temperature Probes has been designed for steam autoclave sterilization temperatures up to 134°C (or 273°F).

SGX understands that develop is expensive and how important time to market can be for our customers. To ensure the development time is kept to a minimum SGX offers a range of development kits for all of our gas sensor range.

Thermometrics GE-1856 Intake Air Temperature Sensor (IAT) monitors the temperature of the incoming intake air for an engine and provides a signal output that is proportional to air temperature. This signal can be used as an input to provide a signal to an ECU (Engine Control Unit). The ECU then uses this information to adjust fuel delivery and optimize the air-to-fuel ratio to produce the most efficient combustion. This sensor is also suitable for air duct temperature measurement in non-condensing HVAC applications.Thermometrics GE-1856 Intake Air Temperature Sensor (IAT) monitors the temperature of the incoming intake air for an engine and provides a signal output that is proportional to air temperature. This signal can be used as an input to provide a signal to an ECU (Engine Control Unit). The ECU then uses this information to adjust fuel delivery and optimize the air-to-fuel ratio to produce the most efficient combustion. This sensor is also suitable for air duct temperature measurement in non-condensing HVAC applications.

The Thermometrics GC Series (GC11/GC14/GC16) of Glass-Encapsulated NTC Chip Thermistors consists of small glass-encapsulated chip thermistors on fine diameter platinum alloy lead wires. Suitable for temperature measurement, control and compensation applications, as well as self-heated applications, such as liquid level sensing or gas flow measurement.

The CR-1 Harsh Environment Chip Thermistors are Sn-coated Alloy 52 leads with high performance acid and moisture resistant coating.Our NTC chip thermistors are ideal for harsh environment applications and high volume assembly.

The NovaSensor NPR-101 Harsh Media Pressure Sensor is a silicon-based MEMS device using “Backside Absolute Pressure” technology designed for harsh media exposure, which eliminates the direct contact of the sensing circuitry with the applied media. The device is coupled with an ASIC to provide a ratiometric output proportional to the applied pressure. Integrated diagnostics included.

The NovaSensor NPI-15 Series High Pressure Sensors employs SenStable® processing technology, providing excellent output stability. The NovaSensor® NPI Series incorporates state-of-the-art IsoSensor technology, which gives the OEM user the best in price and performance. They are designed to operate in hostile environments and yet give the outstanding sensitivity, linearity, and hysteresis of a silicon sensor. The piezoresistive sensor chip is housed in a fluid filled cylindrical cavity and isolated from measured media by a stainless steel diaphragm and body.

As with all NovaSensor® silicon sensors, the NPI Series employs SenStable® processing technology, providing excellent output stability.

The NovaSensor NPI-15VC Series of voltage-compensated, media isolated Pressure Sensors designed to operate in hostile environments while providing outstanding sensitivity, linearity, and hysteresis. The NovaSensor® NPI Series incorporates state-of-the-art IsoSensor technology, which gives the OEM user the best in price and performance. They are designed to operate in hostile environments and yet give the outstanding sensitivity, linearity, and hysteresis of a silicon sensor. The piezoresistive sensor chip is housed in a fluid filled cylindrical cavity and isolated from measured media by a stainless steel diaphragm and body.

As with all NovaSensor® silicon sensors, the NPI Series employs SenStable® processing technology, providing excellent output stability.

The NovaSensor P2701 is a high sensitivity, low pressure sensor die. When excited with 5. 0 V, the P2701 die produces a millivolt output that is proportional to input pressure. It is usable over a wide pressure range of 1.25 kPa (5” H2O) to 7. 5 kPa (30” H2O). With NovaSensor’s SenStable® process, the P2701 die provides excellent long-term stability and repeatability.

The NovaSensor P122 High Silicon Pressure Sensor Die are piezoresistive pressure sensors offered in a miniature 0.10 in x 0.10 in (2.5 mm x 2.5 mm) die. When excited with 1.0 mA, the P122 produces a millivolt output that is proportional to input pressure.

The Telaire T9602 Humidity & Temperature Sensor is a fully calibrated and temperature compensated Humidity and Temperature Sensor for OEM installations. Telaire T9602 offers the most advanced and cost effective humidity and temperature sensing solution for virtually any type of application. Based on our own capacitive polymer sensor chip and a CMOS integrated circuit with EEPROM are integrated into an easy mount OEM package.

The Telaire ChipCap 2 offers the most advanced and cost effective humidity and temperature sensing solution for virtually any type of application. A capacitive polymer sensor chip and a CMOS integrated circuit with EEPROM are integrated into one embedded system in a reflow solderable SMD package.

Individually calibrated and tested, ChipCap 2 performs at ±2% from 20% to 80% RH (±3% over entire humidity range), and is simple and ready to use without further calibration or temperature compensation.

The HVAC sensor family has been designed to feedback the position of the cold/hot air flap in the car´s HVACR system. High accuracy (2% linearity) and low cost are among its main advantages.

Over 120 million-plus HVAC custom sensors, delivered to a major automotive supplier, for over ten years with an PPM rate below 1 are some the impressive figures achieved by Piher for motor control feeback sensing applications related to HVAC.

The Protimeter Hygromaster 2 is the latest in hand held hygrometry technology. Features outstanding performance with a simple and easy to use interface with multiple Psychometric calculations and a non-contact surface IR temperature probe.

The Thermometrics Inline Flow-Through Temperature Sensors monitor the temperature of a fluid that passes through it. A system control module receives this temperature reading and uses a control loop to control the overall system temperature. This could be engine temperature, heater temperature, industrial supply temperature, etc.

Thermometrics CL Series of Inrush Current Limiting Thermistors consist of a disc thermistor with uninsulated lead-wires, and are used to control inrush current when switching power supplies. The main purpose of limiting inrush current is to prevent components in series with the input to the DC/DC convertor from being damaged. Typically, inrush protection prevents nuisance blowing of fuses or breakers as well as welding of switch contacts.

The Kaye product range is relied upon by the world’s leading pharmaceutical and biotechnology companies to validate and monitor critical assets and processes like sterilization as required by governing regulatory bodies.

Kaye products are designed to meet the most demanding requirements for process improvement, thermal validation and environmental monitoring.

The Kaye Validator AVS is a state of the art temperature validation system design that meets industry and regulatory (FDA/GAMP) requirements for thermal validation.

The Validator AVS combines high accuracy measurements, automated sensor calibration, intuitive metro style user interface and extensive reporting to simplify the complete validation process.

The Kaye product range is relied upon by the world’s leading pharmaceutical and biotechnology companies to validate and monitor critical assets and processes like sterilization as required by governing regulatory bodies.

Kaye products are designed to meet the most demanding requirements for process improvement, thermal validation and environmental monitoring.

Kaye Valprobe is an easy to use wireless thermal validation solution for standard processes.

The ValProbe system's wireless probe design eliminates the need for hard-wired sensors, simplifying access to hostile, remote or hard to reach environments. The ValProbe system is ideally suited for applications where high measurement accuracy and regulatory compliance are priorities:

Pharmaceutical Processing
Medical Device Sterilization
Food Processing
Environmental Monitoring

The NovaSensor NPI-19 Series of Low and Medium Pressure Sensors incorporates IsoSensor technology, which gives the OEM user the best in price and performance. They are designed to operate in hostile environments and yet give the outstanding sensitivity, linearity, and hysteresis of a silicon sensor. The piezoresistive sensor chip is housed in a fluid filled cylindrical cavity and isolated from measured media by a stainless steel diaphragm and body. As with all NovaSensor® silicon sensors, the NPI Series employs SenStable® processing technology, providing excellent output stability. Available in either constant current or constant voltage version. The modular design allows for a variety of pressure port modules, which are hermetically welded to the sensor header module. Other standard port styles are available.

The NovaSensor P1300 Low Pressure Silicon Pressure Sensor Die are highly reliable, solid state pressure sensors, offered in a miniature 2.7 mm x 3.2 mm die. When excited with 1.5 mA, the P1300 produces a millivolt output that is proportional to input pressure. The sensor will operate with a constant voltage supply; however, the sensitivity will change –0.23%/°C. The P1300 is available as a diff erential and gauge sensor. NovaSensor’s SenStable® process provides good long-term stability and excellent repeatability. The die substrate must be connected to the positive power supply in order to maintain good long-term stability. To achieve this, +INa is connected to the sensor as well as the substrate pad, which is labeled with an “S.”

The NovaSensor P1302 Low Pressure Silicon Pressure Sensor Die is a high-sensitivity silicon piezoresistive pressure sensor die that is well-suited for measuring low-pressure. In addition to superior stability from our patented SenStable® process, the P1302incorporates a bonded glass pedestal to provide thermal and die attach stress isolation.

The P1302 piezoresistive pressure sensors are offered in a miniature 0.11 in x 0.13 in (2.7 mm x 3.2 mm) die. When excited with 1.5 mA, the P1302 produces a millivolt output that is proportional to input pressure. The P1302 is available as a differential and gage sensor.

MAC820 handheld vibration meter

Includes MachineryMate800, software unlock code for downloadable DataMate PRO software which supports 1,000 machines/10 points each, strobe attachments, Bluetooth headphones and carrying case.

MD055 is a two-footed magnet for use on round surfaces

Two-pole magnetic mounting base 55 lb force, 1/4-28 tapped hole, non-isolated, 1/25' diameter.

NovaSensor P162 Medical Silicon Gage Pressure Sensor Die are piezoresistive pressure sensor die offered in a miniature 1150 x 725 mm die that is small enough for three French catheters. The small die size is made possible by NovaSensor’s proprietary Silicon Fusion Bonding (SFB) process. When excited with an AC or DC voltage source, the P162 produces a mV output that is proportional to input pressure.

The P162 is in a halfbridge design, where external resistors are needed to complete a full bridge configuration.

The NovaSensor P562 Medical Silicon Pressure Die is a piezoresistive pressure sensor that is specifically designed for medical applications. Low linearity errors and low input and output impedance make the P562 an industry standard for disposable pressure sensor die. The sensor die is radiation tolerant for newer sterilization methods. Wire bonds are located on one side to minimize package width for DPT’s and IUP’s. Choose an open bridge wirebond configuration depending on your compensation circuit. Sensitivity can be easily scaled with external circuitry to meet the AAMI standard of 5 :V/V/mmHg sensitivity.

The NovaSensor P112 Medium Pressure Sensor Die is a piezoresistive pressure sensor offered in a miniature 2.7mm x 3.2 mm (0.10 in x 0.12 in) die. When excited with 1.0 mA, the P112 produces a millivolt output that is proportional to input pressure. The P112 is available as an absolute pressure sensor where the media pressure is referenced to an internal vacuum sealed in the die. The P112 is also available as a diff erential and gauge sensor.With NovaSensor’s SenStable® process, the P112 will provide very good long-term stability and excellent repeatability. With NovaSensor’s “fl at process,” the P112 can be temperature compensated for either a constant current or a constant voltage power supply.

The NovaSensor P883 Medium Pressure Silicon Sensor Die is a general purpose silicon piezoresistive pressure sensing element that utilizes our patented SenStable® process for superior device stability, and is particularly well suited for high volume applications for which cost is paramount. The P883 can optionally utilize a bonded-glass pedestal that provides both thermal and die-attach stress isolation.

The NovaSensor P111 Medium Silicon Pressure Sensor Die are piezoresistive pressure sensors offered in a miniature 0.10 in x 0.12 in (2.7mm x 3.2 mm) die. When excited with 1.0 mA, the P111 produces a millivolt output that is proportional to input pressure. The P111 is available as an absolute pressure sensor where the media pressure is referenced to an internal vacuum sealed in the die. The P111 is also available as a differential and gage sensor. With NovaSensor's SenStable process, the P111 will provide long-term stability and excellent repeatability.

SGX Sensortech announces their new range of low power catalytic flammable sensors. The These low power flammable gas sensors are designed specifically for portable flammable gas detection instrument applications within Mining, Automation and control, Industrial health and safety, Oil and gas and utilities.

MF040 is a flat magnet for use on flat surfaces

Flat magnetic mounting base 40 lb force, 1/4-28 tapped hole, non-isolated, 1" diameter

The attachments aren’t just included, they’re built in.

The Protimeter MMS2 is the industry’s most advanced all-in-one moisture meter. Its ergonomic, 4-in-1 design allows one-handed operation to measure moisture on and below the surface as well as ambient air humidity. An infrared thermometer which calculates the difference between dew point and surface temperature, is just one of the many advances designed to assess moisture in new/refurbishing projects and help diagnose moisture-related problems in existing buildings.

All Protimeter instruments have a two-year warranty.

Introducing the Protimeter MMS2 Flooring Kit. A multi function moisture meter with the most innovative humidity sleeves system available.

Measurements Include:
In situ relative humidity and temperature - required for ASTM F2170 standard
Relative humidity and temperature in the ambient conditions - required for
ASTM F2170 standard
Surface temperature - required for ASTM F2170 standard
Noninvasive instant moisture evaluation used prior to in-situ RH moisture test
Pin type moisture measurement, evaluating wood floor materials
Data logging

By Amphenol Advanced Sensors | Protimeter

The Thermometrics A-1737 Motor Coil Temperature Sensor is used on a starter generator to provide temperature measurement of the motor coil. Typically mounted on the neutral bar, it detects increases in current that would indicate a failure that could lead to a stall. The sensor can also be used to monitor the motor windings temperature and warn of an over-temperature conditions.

In automobile seat applications the seat may be linearly movable, either manually or automatically via electromechanical means, on an associated track assembly. A sensor may provide a signal representative of the linear position of the seat on the track for a variety of purposes, e.g. to control deployment or the force of an air bag, to feedback the motor position of the seat in connection with a seat position memory feature, etc.

Sealed and featuring a clutch function, different MT models are available according to their fixation means and number of turns allowed. The product can be easily customised to meet customer´s requirements.

Absolute position is mechanically stored so there is no need of active electronics thus avoiding problems such as memory being lost by current shortages.

The MTS360 provides a true breakthrough in contactless sensor technology by combining a through-shaft design with 360º absolute position feedback in an ultra miniature size. The result is the smallest fully featured rotary sensor on the market with reliability up to 25 million cycles.

The MTS 360 relies on patented Hall effect technology to enable for the first time true non-contacting through-hole shaft sensing using standard SMD features.

The device offers electrical angles up to 360° with no dead band and linearity as low as ±0.5%. Rated for use at -40ºC to +150ºC, the sensor can operate up to 300 rpms and can be programmed with full scale output with angles shorter than 360 degrees. Output is selectable between Analog, PWM 12 bits or Serial Protocol (SPI) at 14 bits and includes a second output channel to provide a programmable switch signal. A redundant version with a dual core sensor in the same package is also available.

Designed with the sensor directly mounted onto a PCB, the innovative MTS-360 Sensor/PCB Combo package allows engineers to easily mount a fully featured rotary sensor without first having to design a printed circuit board for the sensor. The result is time-savings and convenience.

The MTS-360 Sensor/PCB assembly is available with or without 2.54 mm pitch connector, both easily secured with standard M3 screws. The entire assembly measures just 35mm wide by 36mm long, allowing for applications with tight packaging constraints.

The new MTS-360PCB Mechanical Mount sensor model incorporates all the breakthrough sensor technology performance features of the original MTS-360 by merging a through-shaft design with 360º absolute position feedback in a small size package. The result is an extremely small fully featured rotary sensor with reliability up to 50 million cycles. The MTS-360 relies on patented Hall effect technology to enable true non-contacting through-hole shaft sensing now using a simple three eared mounting. The standard model features a 4mm double D-flat through-hole and (3) slotted mounting holes allowing final rotational adjustment at assembly.

6mm low cost carbon potentiometer. For long life and lead free reflow soldering please use the product N6R.

The N6R is a unique, fully RoHS ready miniture potentiometer with all the features of the traditional full size types. The combination of the 10k mechanical life, reduced form factor, RoHS reflow compatibility and overmoulding technology provides market leading performance in a compact, robust design.

The N6R Long Life "E" version has been conceived for the appliance and automotive industries to provide a cost effective solution. Further options include improved linearity, a 360º endless rotation option and a selection of shafts and knobs. Ask for double reflow potentiometers and geared potentiometers here.

The NovaSensor NPR-101 Harsh Media Pressure Sensor is a silicon-based MEMS device using “Backside Absolute Pressure” technology designed for harsh media exposure, which eliminates the direct contact of the sensing circuitry with the applied media. The device is coupled with an ASIC to provide a ratiometric output proportional to the applied pressure. Integrated diagnostics included.

Features:
* High reliability.
* Simple construction (only 3 component parts).
* Over-moulding manufacturing technique.
* Plastic or metal clip versions available.
* Various fixation means: clip type (inward/outward actuating), locating pins,...
* Provides a low cost, highly reliable solution for all position sensing applications: automotive seat position memory, central locking, headlamp position and rear-view mirror position sensors.

The Thermometrics Type CSP Temperature Standards are ultrastable probe thermistors which have been calibrated to an accuracy of 0.01°C. The standard unit has a thin, conformal coating of silicone rubber over the entire unit; this makes it suitable for immersion in a water bath. They are also available with stainless steel sensor housings, or they can be encapsulated into various sheaths.

Epoxy-coated thermistors are generally used at temperatures below 150°C. Choose from our extensive range of resistances and beta values.

Thermometrics offer two types of Thermistors:
* Interchangeable Thermistors
* Type RL Epoxy Thermistors

Thermometrics Diode Series of Glass-Encapsulated NTC Thermistors consists of a range of NTC chip thermistors in DO-35 style glass package (diode outline) with axial solder-coated copper-clad steel wires. Glass body provides hermetic seal and voltage insulation and excellent stability. Designed for accurate temperature measurement, control and compensation in various applications, including automotive, telecom, HVAC and white goods. Also for use in temperature sensing for household appliances, such as rice cookers, electronic ranges and ovens, and industrial products, such as pharmaceuticals, chemicals, and components.

Thermometrics offers point-matched Radial Lead Disc Thermistors with bare lead wires in a wide range of material systems.

NTC Thermistors- Radial lead / Applications / Description
Thermometrics -Uncoated Disc Radial Leads NTC Thermistor Type RL10 / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Point-matched disc thermistor with bare lead-wires.
Thermometrics - Uncoated Disc With Radial Leads NTC Thermistors Type RL14 / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Point-matched disc thermistor with bare lead-wires.
Thermometrics - Uncoated Disc With Radial Leads NTC Thermistors Type RL20 / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Point-matched disc thermistor with bare lead-wires.
Thermometrics - Uncoated Disc With Radial Leads NTC Thermistors Type RL30 / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Point-matched disc thermistor with bare lead-wires.
Thermometrics - Uncoated Disc With Radial Leads NTC Thermistors Type RL35/40/45 / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Point-matched disc thermistor with bare lead-wires.
Thermometrics - Uncoated Disc With Radial Leads NTC Thermistors Type SA / "Suitable for temperature measurement, control and compensation Suitable for PCB and probe mountings" / Interchangeable thermistor with bare lead-wires.

The Thermometrics Oil Pressure Switch can be used in all vehicles monitors the engine oil flow when the engine starts. It can detect oil pressure and enables the EMS ECU to check for the lack of oil. It can also send an alarm signal to the driver, helping to avoid engine damage due to overheating

Thermometrics Oil Temperature Sensor (OTS) monitors the temperature of the engine oil in a vehicle and displays this measurement to the vehicle’s occupants. If a vehicle operates at too high a temperature, the engine can be in danger of damage. The OTS prevents this by allowing the operator to stop the vehicle and switch off the engine if the temperature of the oil gets too high as a result of an over heated engine.

Thermometrics Outside Air Temperature Sensor (OAT) measures the temperature outside of a vehicle's passenger compartment. It relays the outside air temperature to the controller of the automatic HVAC system. The controller uses this temperature to help control the interior temperature of the vehicle. The sensor also provides the vehicle occupants with temperature readings from outside the car. This information is particularly useful when driving under near-freezing or freezing conditions. The sensor is usually mounted inside or near the front bumper or in the side mirror.

The Thermometrics JB Series Glass-Encapsulated Thermistor is housed in a stainless steel probe body with PTFE leadout wires, terminated with a connector assembly. Typical applications include domestic ovens and combination microwaves.

16mm potentiometers enclosed in plastic housing with a shaft and IP54 ingress protection rating.

These provide full customisation capabilities, such as:
* Electrical and mechanical specifications.
* Custom mechanical life.
* Special outputs (linear, log, anti-log, bespoke).
* Absolute or independent linearity values.
* Special resistance value and tolerance.
* Mechanical and electrical angles.
* Switch.
* Selectable busing and shafts lenghts and shapes.

PC420VR-10-EX loop powered sensor

PC420VR-10-IS loop powered sensor

The Thermometrics Pipe Clip Temperature Sensors are designed for industrial HVACR applications with the ability to mount directly to a metallic pipe. They consist of a NTC thermistor on a ceramic/metal shoe assembly seated in a polymer housing with flexible twin cable connections. The housing is fitted with a spring metal clip for pipe attachment. These sensors have been used in industrial applications for decades with a proven robust quality record in the field.

This product family has been specifically developed to allow the integration of otherwise large and expensive external mechanisms into the body of the majority of the 6, 10 & 15 mm potentiometer series thus allowing a high range of configurations: special tapers, tolerances, linearity, cut track, etc.

This detent design not only adds a "click" sensation of position, but also offers enormous savings in both cost and space for any given application.
Strong and weak detents can be mixed as per cutomer´s request.


- Replacement for:
• Existing customer detent mechanisms.
• Multi-pole switches.
• 3 or 4-bit absolute encoders (connecting to microprocessor analogue input).
- Analogue signal presets.
- Temperature control settings.
- Relay Timers.

PT´s with detents also lend themselves perfectly to industrial and domestic power tool applications where the detents prevent accidental movement of the potentiometer under vibration.

If high torque detents are required please see our Detent Control Mechanism (DCM) series datasheets. As previously highlighted, this family is indispensable wherever both cost and space saving reductions are important, or where a series of fixed positions along the potentiometer travel are required.

The Thermometrics Temperature Standards consist of ultra-stable thermistor probes assembled into thin wall stainless steel housings with shielded extension leads.

The thermistors used receive special processing to ensure long term stability. All thermistor temperature standards are ruggedly constructed and are suitable for liquid immersion.

The NovaSensor P1602 Pressure Sensor Die is a piezoresistive pressure sensor offered in a miniature die. When excited with 1 mA constant current, the P1602 produces a millivolt output that is proportional to input pressure. The P1602 is available as an absolute pressure sensor, where the applied pressure is referenced to an internal vauum sealed within the die. With NovaSensor SenStable®, the P1602 will provide very low long-term stability erros and excellent repeatability.

The Modus W Series of Pressure Transmitters are designed to measure low differential pressures of liquids or gases. A wide selection of standard pressure ranges and electrical ratings is available. These transmitters feature: no moving parts to wear out, proven long term stability of piezoresistive devices, only 316 stainless steel in contact with the fluid, and all welded construction.

Series W transmitters are an excellent choice for many HVAC, process and automation monitoring requirements. Typical applications include measurement of differential pressure across flow elements, heat exchangers, pumps, filters, liquid level monitoring and other demanding differential pressure measurement and control applications.

The transmitters are housed in a compact heavy duty gasketted cast aluminum enclosure designed to IP 65 of IEC 529 standards and NEMA 4. The die cast aluminum enclosure incorporates a recessed neoprene gasket to prevent ingress of moisture or dust. Wall mounting holes are enclosed in the cast aluminum box and concealed by the cover. The wall mounting holes and the cover attaching screws are outside the gasketted area. Access to the electrical terminals are made through knockouts on the front of the box. A choice of one or two knockouts and three hole sizes is available to accommodate usage of 1/2" conduit or metric sizes PG11 and PG13. Pluggable terminal block connectors are provided with wire protection and captive terminal screws.

The Series W includes four models: Model W10, Model W20, Model W30 and Model W40. These four models incorporate a variety of power and signal options. The span or zero adjustment is performed with a 20-turn potentiometer for fine resolution. A 50% adjustment in output is possible.

The Series W transmitters have been tested by an accredited laboratory and comply with the European requirements of Council Directive 89/336/EEC for emission measurements per EN50081-1 and immunity tests per EN50082-1.

Printed Resistors PCB are thick-film resistive ink elements designed around customers’ unique assemblies. PIHER’s thick film inks can be printed on a wide range of substrates — from high temperature ceramics to common PCB materials.

Our market-leading thick-film technology can be used to deposit any combination of fixed resistors, switches, sensors, potentiometer tracks and conductors onto virtually any size, shape or PCB form. This versatility offers an enormous range of design possibilities at competitive prices,even in low batch quantities.

Once screened and cured, these resistive tracks can be individually laser trimmed to obtain very accurate tolerances in high volume.

We also offer custom wiper (contact) assemblies as standard products or we can design and manufacture according to customers´ bespoke design requirements.

This technology is ideal for three-wire voltage-divider (potentiometer) designs. Here, we offer in-process calibration and resistive (ohmic) process control, allowing for tight matching within lots and high precision voltage ratios between key points in the circuit.

The PS-10 & PSX-10 potentiometers arespecifically designed for leadfree reflow soldering processes (excellent performance).

This sensor offers a new surface mountable solution for detecting changes in angle and position and converting them into a highly reliable voltage output. The sensor can be processed by standard automated placement equipment and reflow (or lead-free reflow) soldered. For applications where rotor angle is critical, locating pins are available.

The PS15 Series is available with seven different rotor designs and 15 shaft styles. This offering allows Piher to configure a custom sensing solution for virtually any control or position feedback requirement. The result is a customized sensor that maximizes board density, reduces weight and eases assembly while achieving the engineer’s critical sensor design goals for the application.

A wide range of options, including up to 38 detents, allows further customization. Detents not only add a crisp "click" sensation for each position without affecting the original sensor specification or performance, but also offer significant savings in both cost and space; and are particularly advantageous in industrial and domestic power tool applications to prevent accidental movement.

The touchless variable air gap sensor creates immunity to radial and axial play on mobile shafts where significant misalignment results in poor operational performance and labour intensive maintenance programmes. It complements our PS2P-LIN and PS2P-CON series of air-gap non-contact linear and angular position sensors.

A round or arc magnet (where 360º rotation angle is unnecessary) is attached to rotating parts of kit, such as boom loaders, skid steer buckets and hitch arms, and the electronics module to the chassis (or vice versa).

Here, Piher separates the magnet from the electronics module. As an absolute sensor it will not loose the values even after a power failure.

All Piher sensors are compact, low-profile, yet extremely rugged and can be custom-engineered to fit existing mechanical assemblies.

The PS2P-CON sensor creates immunity to radial and axial play on mobile shafts where significant misalignment results in poor operational performance and labour intensive maintenance programmes. It complements our PS2P-LIN and PS2P-ARC series of air-gap non-contact linear and angular position sensors.

A magnet is attached to rotating parts of kit, such as boom loaders, skid steer buckets and hitch arms, and the electronics module to the chassis (or vice versa).

As an absolute sensor it will not loose the values even after a power failure.

All Piher touchless sensors are compact, sealed, low-profile, yet extremely rugged and can be custom-engineered to fit customers´ specifications and existing mechanical assemblies.

The PS2P-LIN linear sensors create immunity to magnet´s misalignment that negatively impacts operational performance and results in labour intensive maintenance programmes. It complements our PS2P-CON and PS2P-ARC series of air-gap non-contact angular rotary position sensors.

A magnet is attached to moving parts of kit, such hydraulic/pneumatic controls & gear selector, and the electronics module to the chassis (or viceversa).

As absolute sensors, they will not loose the values even after a power failure.

All Piher touchless sensors are compact, sealed, low-profile, yet extremely rugged and can be custom-engineered to fit customers´ specifications and existing mechanical assemblies.

The PS-6 & PSX-6 potentiometers were specifically designed for leadfree reflow soldering processes (excellent performance).

The robust PSC-360 is a low-cost high performance non-contacting rotary position sensor for automotive, off-road, medical and industrial applications whithout the limitations of potentiometric solutions (wear, limited electrical angles...) A configurable switch ouptput is integrated within the sensor too.

Full redundancy can be achieved by employing a dual core version or the simple placement of two sensors within the housing.

Sealed and flange mounted for easy positioning when necessary, it provides high stability under harsh environment conditions such as vibration, shock, extreme temperatures / humidity, dither, moisture or dirt. Featuring a modular architecture, electrical & mechanical characteristics can be fully customised to customer´s needs as well as connector configurations.

The robust PSC-360U is a panel mount, low-cost, high performance, non-contacting rotary position sensor for automotive, off-road, medical and industrial applications whithout the limitations of potentiometric solutions (wear, limited electrical angles...) A configurable switch ouptput is integrated within the sensor too.

Full redundancy can be achieved by employing a dual core version or the simple placement of two sensors within the housing.

Sealed and flange mounted for easy positioning when necessary, it provides high stability under harsh environment conditions such as vibration, shock, extreme temperatures / humidity, dither, moisture or dirt. Featuring a modular architecture, electrical & mechanical characteristics can be fully customised to customer´s needs as well as connector configurations.

The PST-360 through / hollow shaft position sensor combines three critical design features; 1) through hole where the shaft passes through the sensor, 2) high accuracy absolute position feedback over up to 360°, and 3) a true non-contacting sensing element. Piher’s design does not rely on gears or other rotating parts.

For more than 20 years PIHER has been manufacturing rotary switches for all types of applications. Cost-effective and highly customiseable products with our huge experience in adapting them to customers´ needs when necessary. We have the best solution for all your rotary switching needs. Our products are widely used in Automotive, Consumer and Multimedia applications due to their excellent performace and quality/price ratio.

ISO TS1649, ISO14001, ISO 9001, Lead-Free compliance and hundreds of satisfied customers are the best presentation card. Here we are presenting to you our Rotary Switches based on our PT series. We strongly recommend you to visit www.piher.net for our PC16, S15 and T-21 rotary switches and our full product range that includes Potentiometers, Encoders and Position Sensors.

10mm carbon potentiometer

Our PT-15 series are worldwide known, they are widely used in the household appliance and automotive market and it is difficult to find a home or a car without one of our "PTs"

6 mm through-hole carbon potentiometer with a high level of customisation possibilities, such as:
* Electrical and mechanical specifications.
* Custom mechanical life.
* Mechanical design.
* Detents.
* Special outputs (linear, log, anti-log, bespoke).
* Absolute or independent linearity values.
* Special resistance value and tolerance.
* Mechanical and electrical angles.
* Switches.
* Custom shafts and knobs.

The Thermometrics PTF Series of PTC Type Thermistors consists of a range of radially-wired bare PTC disc thermistors. They are designed for general purpose over-current and short circuit protection.

The Thermometrics PTO Series of PTC Type Thermistors consists of a range of radially-wire bare PTC disc thermistors for current regulation, circuit protection and temperature measurement and control. Available in a broad range of resistances, transition temperatures and voltage ratings.

The Thermometrics YM Series of PTC Type Thermistors consists of a range of radially wired PTC disc thermistors with silicone resin coating with a wide range of operating current levels. Designed for general purpose over-current, overvoltage and direct over-temperature protection.

Our PT series are worldwide known, they are widely used in the household appliance and automotive market and it is difficult to find a home or a car without one of our "PTs"

15mm cermet potentiometer. Our PT series are worldwide known, they are widely used in the household appliance and automotive market and it is difficult to find a home or a car without one of our "PTs".

The N-15 potentiometer/sensor series has been expanded to incorporate both encoders and rotary switches in the same package configuration allowing the user to design in any one of the three options whilst keeping the same board layout and user interface.

The S-15 switch series has been specifically designed to offer a flexible and customiseable rotary switch/sensor solution for the automotive industry typically employed as multi-position interior/exterior lighting, Traction or Airbag enable/disable controls. The technology developed for the aforementioned S-15 solutions is also available for all types of custom switches however demanding your application may be.

Piher designs and develops seat belt buckle sensors that detects when a buckle tongue is latched. This information is received by the vehicle CPU which can determine some conditions such as driving speed limitation when the buckle tongue is unlatched.

The technology used for this kind of sensors, Reed Switch or Hall Effect, provides superior performance detection even under extreme and challenging environment conditions such as dust, dirt, high vibration or temperature.

The Thermometrics range of Self-Adhering Surface Temperature Sensors are designed for industrial HVACR applications, typically for placement on the external wall of a water tank or boiler reservoirs. They are also suitable for reservoir tanks working in conjunction with solar panel water heating systems. This range of adhesive pad sensors detect over-temperature resulting from a malfunction or a dry-fire. Thermometrics range of Self-Adhering Surface Temperature Sensors are designed for industrial HVACR applications, typically for placement on the external wall of a water tank or boiler reservoirs. They are also suitable for reservoir tanks working in conjunction with solar panel water heating systems. This range of adhesive pad sensors detect over-temperature resulting from a malfunction or a dry-fire.

Pressure sensitive adhesive tapes loaded with ceramic powders provide high thermal conductivity and thus excellent heat transfer from the heat source to a NTC thermistor while maintaining appropriate levels of dielectric strength. An adhesive lined foam backing tape provides air and moisture resistance with optional WRC (5470) water safety and DIN 4102 part 1 (B3) fire safety approvals.

SF8 cementing pad, 1/4-28 integral stud, 1" diameter, 21.5 grams

The Single solar sensors are mounted on the IP panel near the front window. The single solar sensor has one photo diode cell inside and is used in the independent type ATC, by sensing the amount of light left to right, using angle light activating filters. The sensor uses the amount of outside sunlight coming into the vehicle to help control the vehicle’s HVAC system.

10mm potentiometers enclosed in plastic housing with a shaft and with IP54 ingress protection rating.

15mm potentiometers enclosed in plastic housing with a shaft and with IP54 ingress protection rating.

The NovaSensor NPH Series of Solid State Medium Pressure Sensors offer reliability at a low cost and small size. They are available in gauge, absolute and differential pressureversions. The NPH Standard TO-8 package is suitable for PC board mount. They are also compatible with non-corrosive gases and dry air.

An integrated circuit silicon sensor chip is housed in a standard TO-8 electrical package that is printed circuit board mountable. The latest techniques in micromachining have been used to ion-implant piezoresistive strain gauges into a wheatstone bridge configuration that is integrally formed on a micromachined silicon diaphragm. As with all NovaSensor silicon sensors, the NPH Series employs SenStable® processing technology, providing excellent output stability. Constant current excitation to the sensor produces a voltage output that is linearly proportional to the input pressure. The user can provide standard signal conditioning circuitry to amplify the 100 mV output signal. The sensor is compatible with most non-corrosive gases and dry air. A laser-trimmed, thick-film resistor network on a hybrid ceramic substrate provides temperature compensation.

The NovaSensor NPH Series of Solid State Medium Pressure Sensors offer reliability at a low cost and small size. They are available in gauge, absolute and differential pressureversions. The NPH Standard TO-8 package is suitable for PC board mount. They are also compatible with non-corrosive gases and dry air.

The Model ST-15 offers engineers an endless rotation version of the popular PT-15 rotary potentiometer. This new 360º version adds endless clockwise (CW or CCW) rotation as a part of the current features of the PT-15s already highly configurable mechanical and electrical specifications. That means a wide variety of off-the-shelf mounting methods, custom ohmic (resistance) values, tight linearity performance, along with the 7 different rotor designs and 15 standard shaft styles.

This potentiometer offers product designers the flexibility of allowing users full rotational access across the normal stops that have, up to now, limited mechanical rotation. With this design feature, engineers can now design product command features over a 340º range (active electrical travel). For maximum design versatility, the endless rotation feature can be combined upon request with detents to provide users tactile feedback on each setting and selection – with up to 51 unique detent positions. Virtually any appliance rotary feedback requirement can be configured using the PT-15s wide range of standard features. Other interesting optional features include flame-retardant plastics (meets UL Standard 94 V0), detents, rotors and shafts, long cycle life, SMT mounting and custom electrical angles.

The NovaSensor NPI-12 Series of Stainless Steel Media Isolated Sensors provide a cost effective solution for applications that detect tube blockages and pump performance. The NPI-12 Series is intended to mount adjacent to flexible tubing to sense tube expansion. Cleanliness is assured with the NPI-12 Series stainless steel finish.

The NPI-12 Series incorporates state-of-the-art IsoSensor technology, which gives the OEM user the best in price and performance. They are designed to operate in hostile environments while providing outstanding sensitivity, linearity and hysteresis. The piezoresistive sensor chip is housed in a fluid filled cavity and isolated from the measured media by a stainless steel diaphragm and body. As with many NovaSensor® silicon sensors, the NPI-12 Series employs SenStable® processing technology, which provides excellent output stability.

SGX Sensortech offer a range of NDIR gas sensor components within Explosion proof certified housings designed for the measurement of atmospheric measurement of Hydrocarbons and Carbon dioxide gases. The sensors are designed specifically for fixed instrumentation for OEM use within the Mining, Automation and control, Industrial health and safety, Oil and gas and utilities. These sensors are required to be fitted with OEM electronics, the analogue signal requires linearization and temperature compensation within the OEMs electronics.

The NovaSensor NPA Series of Surface Mount Pressure Sensors is a new family of OEM miniature pressure sensing products offering best in class performance for OEM applications in healthcare, industrial and transportation markets. Packaged in an industry standard surface mount SOIC14 pin package, the NPA Series is available in Gage, Absolute or Differential pressure ranges from 0 to 10" H20 to 0 to 30PSI with either un-calibrated millivolt outputs or in fully calibrated, amplified analog or 14bit digital outputs.

The NPA sensor is intended for printed circuit board mounting and delivered in optional tape and reel ready for automated manufacturing and reflow soldering operations.

The NovaSensor NPP-301 Series features silicon pressure sensors in surface mount packages. An ultra-small Silicon Fusion Bonded (SFB), ultra-high stability SenStable® piezoresistive chip from NovaSensor is placed in a plastic package that exploits high volume, leadframe package technology to bring forth a low-cost sensor alternative to the OEM user.

The NPP-301 Series produces a voltage output that is linearly proportional to the input pressure. The user can provide NPP Series products with signal conditioning circuitry to amplify the output signal or to maximize OEM value added. The NPP-301 Series is compatible with most non-corrosive gases and dry air.

One of the industry’s first and best-selling dual-function moisture meters.

The right moisture meter makes all the difference! And we’ve made improvement to enhance the Protimeter Surveymaster. This versatile pin and non-invasive meter is ergonomically designed for easy, one-handed operation to measure moisture in buildings and other related structures both on and below the surface. This allows you to assess moisture levels for new or refurbishing activities and diagnose moisture-related problems in existing buildings.

All Protimeter instruments have a two-year warranty.

16mm carbon potentiometers with excellent rotational torque and high mechanical endurance.

21mm carbon potentiometers with excellent rotational torque and high mechanical endurance.

The Thermometrics NTC Type AB6 Series Thermistor Assemblies consist of small thermobeads and GCs (chip-in-glass) that are welded to insulated extension leads. Thermobead and GC assemblies are used where a small thermistor must be further connected to longer leads, and for applications requiring fast response measurements in confined spaces.

The thermobeads or GC (chip-in-glass) are hermetically sealed in glass and have fine diameter 0.0007 in to 0.004 in (0.01778 mm to 0.1016 mm) platinum alloy leads. The platinum leads are cut short and welded to insulated extension leads and the joints are covered in one of several insulation types, depending upon the application or environment. The assembly is then ready for insertion into hypodermic needles, catheters or other small housings that require extended leads.

Thermometrics NTC Type Surface Mount Devices (SMD) are intended for temperature measurement, control and compensation. They are suitable for standard soldering techniques and availabe in a range of sizes, including 0402, 0603, 0805 and 1206.

Thermometrics ZTP-015 Thermopile Infrared (IR) Sensor is used for non-contact surface temperature measuring. The ZTP-015 Model consists of thermo-elements, flat infrared filter and a thermistor for temperature compensation, all in a hermetically-sealed TO-46 (18) package. There are also a variety of filters available to help maximize performance in specific applications.

Thermometrics ZTP-315 is a Thermopile Infrared (IR) Sensor that is used for non-contact surface temperature measuring. The ZTP-315 Model consists of thermo-elements, flat infrared filter and a thermistor for temperature compensation, all in a hermetically-sealed TO-46 (18) package. There are also a variety of filters available to help maximize performance in specific applications.

Thermometrics ZTP-188MA Thermopile Infrared (IR) Sensor Module is used for non-contact surface temperature monitoring and presents temperature-compensated 8 linear array outputs via I2C with optics (silicon lens). It can also provide compatibility with the customer’s device without the need for recalibration. The ZTP-188MA uses 4-wire connections: two signals for I2C output, single power supply and ground. The sensor is fully-calibrated with a wide object and ambient temperature range. Lens for different fields of view are available on request.

Thermometrics ZTP-188ML Thermopile Infrared (IR) Sensor Module is used for non-contact surface temperature monitoring and presents temperature-compensated 8 linear array outputs via I2C with optics (silicon lens). It can also provide compatibility with the customer’s device without the need for recalibration. The ZTP-188ML uses 4-wire connections: two signals for I2C output, single power supply and ground. The sensor is fully-calibrated with a wide object and ambient temperature range. Lens for different fields of view are available on request.

Thermometrics ZTP-315MIH Thermopile Infrared (IR) Sensor Module is used for non-contact surface temperature monitoring. It presents temperature-compensated single outputs via voltage output with optics (glass lens for high temperature detection). It can also provide compatibility with the customer’s device without the need for recalibration. The ZTP-315MIHuses 3-wire connections for output signal, single power supply and ground. The field of view is approx ±9 degrees for 50% normalized output with a total size is only 33 mm X 17 mm.

Protimeter TimberMaster is an advanced moisture meter specifically designed for the timber industry. It is ideal for a range of quality control applications associated with moisture levels within all wood products.

When precise wood moisture measurements are required, there is no substitute for the Protimeter TimberMaster

The NovaSensor NPX1 Tire Pressure Sensor represents the next-generation Remote Tire Pressure Monitoring (RTPM). NPX1 integrates a silicon pressure sensor, 8-bit RISC processor and a LF-input stage to meet market demands for flexible, customer specific behavior/solutions and overall system cost reduction. The programmable version of this sensor is available for development purposes, allowing the customer to download the application code in an electrically programmable EEPROM version.

This tire pressure sensor is intended for developing the application specific program. In order to ensure high reliability, the NPX1 sensor has the measurement routines (pressure, temperature, and supply voltage) implemented in ROM.

Thermometrics Transmission Fluid Temperature Sensor (TFT) measures the temperature of transmission fluid. It provides input to the control module to modify shift patterns for smoother shifting in automatic transmissions, and also provides over-temperature protection by locking the torque convertor.

The Thermometrics TSD-10 module measures the turbidity (amount of suspended particles) of the wash water in washing machines and dishwashers.

The Thermometrics TST-10 module measures the turbidity (amount of suspended particles) of the wash water in washing machines and dishwashers.

The TSW-10 module measures the turbidity (amount of suspended particles) of the wash water in washing machines and dishwashers. An optical sensor for washing machines is a measuring product for a turbid water density or an extraneous matter concentration using the refraction of wavelength between photo transistor and diode. By using an optical transistor and optical diodes, an optical washing machine sensor measures the amount of light coming from the source of the light to the light receiver, in order to calculate water turbidity.

The Thermometrics NTC Type JR Series of Chip Thermistors in Eyelet Tag are chip thermistors with insulated flexible wires and housed in an eyelet tag. Suitable for surface temperature measurement. Typical applications include semi-conductor heatsinks and enclosure panels.

Custom touchless magnetic Hall effect variable air gap angle/position sensor maintains stable electrical output and specified linearity on mobile shafts despite radial and axial movements of over +/- 5mm.

This sensor will deliver the same level of precision and stability throughout its life as the first day it was installed -despite extremes of vibration, shock, temperature and contamination.
A round or arc magnet (where 360º rotation angle is unnecessary) is attached to rotating parts of kit, such as boom loaders, skid steer buckets and hitch arms, and the electronics module to the chassis (or vice versa). As an absolute sensor it will not loose the values even after a power failure.

The new VOC air quality module from SGX Sensortech is specifically designed for indoor air quality applications. The module has a calibrated digital I2C output, ranged up to 2000 ppb isobutylene (VOC). The modules also have an output of the derived Carbon dioxide level calculated from the increase in VOC levels. The sensors are designed specifically for fixed or portable instrumentation for the OEM to use within the building air quality control instrumentation. This VOC sensor can be combined with a standard NDIR Carbon dioxide air quality sensor or used a low cost sensor for VOC measurement and a derived Carbon dioxide measurement.

The Telaire T8000-R Series is a low cost, high performing CO2 and temperature transmitter with relay for building controls and indoor growers markets. It works seamlessly with building automation systems, and allows you to simply and effectively control fresh air into a ventilated space to meet regulated standards, providing immediate energy savings. Relay control can be used to control fresh air when no building automation system is available. The Telaire 8000-R series can also be used with its built-in relay to control CO2 producing equipment to assist with plant growth.

The Telaire T5100-LED Series offers low cost, high performing CO2 transmitters for the building controls market. It works seamlessly with building automation systems, and allows you to simply and effectively control fresh air into a ventilated space to regulated standards, providing immediate energy savings.

The Telaire T5100 Series offers low cost, high performing CO2 transmitters for the building controls market.

The Telaire Ventostat 8000 Series represents a full range of wall mount carbon dioxide, humidity and temperature transmitters with display options plus active humidity and temperature outputs.

Thermometrics Water Temperature Sensor (WTS) monitors the temperature of the coolant that is being pumped around the engine block to cool the engine to notify the driver of the vehicle if the engine starts to overheat. The goal is to relay an over-temperature engine temperature to the driver, so that the vehicle can be stopped and the engine switched off before the heat causes any permanent damage to the engine.

The Thermometrics JC and JW Series of Clip-On Pipe and Surface Sensors consists of a range of temperature sensing elements on a ceramic/ metal shoe assembly, held in a polymer housing and provided with connector tabs. The housing is fitted with a spring metal clip for pipe attachment. The elements available are NTC, PTC, SLN (silicon linear PTC) and PRT (Pt). Suitable for use in conditions of high condensation and occasional immersion in water. Typical applications include gas boiler control, domestic water systems, air conditioners, radiator inlet-outlet, electric showers and vending machines.

The Thermometrics Waterproof IP68 Temperature Sensors include Types JI and JIC NTC Thermistors. Both types are molded onto a flexible circular cable. The tip and outer cable insulation material is thermoplastic elastomer rubber. The tinned copper conductors have individual polypropylene insulation. Type JIC offers the option of a stainless steel housing.

Targeted for Powertrain and other Critical applications, the Z-15 has been specifically designed to be integrated within the existing final application (throttle body, air-intake valve…) to avoid the duplication of costs associated with the standard “bolt-on” alternatives that prevail in the marketplace.
Moreover, because of the cost effectiveness of the Z-15 solution, TRUE redundancy can be achieved employing two or more ganged Z-15’s.
