RF Interconnects

  • 1.85MM Series
    1.85MM Series
    The 1.85mm connector was designed for mode free operation through 65 GHz. The interface uses a mostly air-dielectric with a support bead that is set back in the body of the connector to reduce bead interaction in a mated pair. Like the 2.92mm and 2.4mm connector, the body has been designed to ensure that the outer conductors engage before the center conductors make contact. The 1.85mm interface uses an M7 thread and is compatible only with the 2.4mm interface. SV Microwave supplies adapters to mate 1.85mm connectors to SMA and 2.92mm connectors.
    More
  • 2.4MM Series
    2.4MM Series
    The 2.4mm connector was developed for use to 50 GHz. This connector series uses a thick outer wall to eliminate the fragility seen in SMA and 2.92mm connectors. The female socket is also strengthened to ensure reliable mating. The 2.4 mm series mates with SMA, 3.5mm and 2.92mm connectors with adapters and can mate with the 1.85mm series without adapters.
    More
  • 2.92MM Series
    2.92MM Series
    The 2.92mm connector was developed for use to 40 GHz. The male pin is shorter than that of an SMA or 3.5mm to ensure that the outer contacts of the male and female connectors engage before the pin and female receptacle do. This ensures that the pin and socket will not see excessive wear and mating stress seen by misalignment in an SMA or 3.5mm connector. The 2.92mm connector also has a thicker wall than a standard SMA. The 2.92mm series mates with SMA and 3.5mm connectors.
    More
  • Advantage No-Braid Trim Connectors
    Advantage No-Braid Trim Connectors
    No-Braid-Trim-X series of connectors feature a termination process that does not require trimming of the braid shield thereby facilitating the cable termination procedure and reducing the time required to terminate the cable. Cable can be stripped using CSTtype LMR® cable stripping tool. Combination hex/knurl coupling nut allows tightening by hand or with a wrench. Chamfered cable entry hole for ease of termination.
    More
  • Blind Mate Antenna Solutions
    Blind Mate Antenna Solutions
    Enables design engineers to convert most existing RF antennas into Blind mate "plug in and forget" quick release antennas, which can be quickly installed and removed from platforms without having to connect or disconnect the coaxial cable. By simply adding a screw-on alignment sleeve, an existing antenna is converted into a plug in device. The interconnecting coaxial connector is fitted with a mating MNC connector which is permanently attached to the aircraft structure via a spring loaded receiver sleeve
    More
  • BMA Series
    BMA Series
    Government designation BMA (Blindmate A) was developed in the 1980's. The originally designated OSP™ connector by M/A-Com has excellent electrical performance up to 22 GHz in a compact size. SV Microwave offers extended frequencies on most BMA connector designs up to 26.5 GHz. With a slide-on interface and a connector durability of 5000 cycles, the BMA blindmate is suitable for high performance microwave applications.
    More
  • BMMA Series
    BMMA Series
    BMMA connector is a subminiature version of the BMA blindmate series. This originally designated OSSP™ connector by M/A-Com has excellent electrical performance at high frequencies up to 28 GHz. There is a complete family of BMMA blindmate connectors and adapters. BMMA connectors are approximately 25% smaller than the BMAs, and are used for applications where space is limited and no special tooling is required.
    More
  • BMZ Series
    BMZ Series
    The BMZ is government designation (Blindmate Z). This connector has low insertion forces and a light spring which allow for high density applications. The BMZ is a miniaturized version of the BZ, a high-frequency connector with slide-on mating. This blindmate has a frequency range of DC-18 GHz and 50 ohms impedance with an interface controlled by MIL-STD-348.
    More
  • BNC Series
    BNC Series
    Developed as a miniature version of the Type C connector, the BNC connector is a miniature quick mating and de-mating RF connector. It features two bayonet lugs on the female connector; mating is achieved with only a quarter turn of the coupling nut. SV Microwave's 50 Ohms BNC series connectors are miniature and lightweight. They are designed to operate at a frequency of DC to 11 GHz and typically yield low reflection through 4 GHz.
    More
  • BZ Series
    BZ Series
    The BZ connector is a high-power blindmate connector with slide-on mating. This originally designated PMA blindmate by Automatic has PTFE dielectric interface, telescoping insulators and wiping outer contacts. BZ blindmate connector applications include GPS navigation systems and antenna connections. The BZ blindmate connector is a mechanically ruggedized blindmate and can handle 6.7 KW to 2 GHz.
    More
  • Compression Mount RF Connectors
    Compression Mount RF Connectors
    SV Microwave manufactures a large variety of solderless precision RF connectors in high frequency bands including the mmWave frequencies. SV offers a variety of cost effective coaxial PCB mount SMA, 2.92mm and 2.4mm connector series. Our solderless application makes assembly fast, easy and without damaging the PCB board. Additionally, SV can customize a PCB footprint design for your application using our latest simulation technology. SV’s line of compression mount coax connectors are available in stripline and CPW/Microstrip options and are ideal for mobile communications (including 4G & 5G applications), wireless test and measurement, high speed digital environments, and much more.
    More
  • M3933/30 Attenuators
    M3933/30 Attenuators
    SV Microwave is the ONLY DLA approved source for these 2.92mm attenuators (DC through 32 GHz). SV's line has the precision, quality and performance unmatched in the marketplace . Our dB values range from 0.5 to 30 dB with low VSWR and flat attenuation. Available in screened and non-screened versions.
    More
  • Millimeter Wave Connectors, Cable Assemblies, Components and Adapters
    Millimeter Wave Connectors, Cable Assemblies, Components and Adapters
    SV Microwave's high frequency millimeter wave product line has the precision, quality and performance needed for the millimeter wave spectrum through 67 GHz. Products include 2.92 mm, 2.4 mm and 1.85 mm and are available as connectors, terminations, attenuators, cable assemblies and customized solutions. These parts are ideal for applications requiring high frequency transmission in the high speed digital, test and measurement, instrumentation and SATCOM markets.
    More
  • Mil-Spec RF Connectors, Adapters and Components
    Mil-Spec RF Connectors, Adapters and Components
    SV has the most extensive RF connector MIL-SPEC offering. We have a long history of supporting DLA and promoting the standardization of RF connectors and components.
    More
  • Multiport Connectors
    Multiport Connectors
    SV offers a wide range of multiport connectors and cable assemblies. SV's precision and expertise enables our ability to manufacture high-density, high performance multiport connectors. Custom and COTS parts are available.
    More
  • Multiport High Density Connectors
    Multiport High Density Connectors
    High Density Interfaces provide connectivity and maintainability with quick mate/de-mate of multiple cable assemblies. High performance M8 Multi-Port, Mini-Multi-Port (MMP) and BMB 38999 contacts fit standard and custom connector shell designs and provide broadband performance up to 40 GHz. These High Density Interconnect products have been developed to provide extended life and full performance in harsh environments. Sealing features are built into the contact interfaces and connector shells, providing redundant assurance of long-term performance in fielded systems that make them very popular in the military aerospace market.
    More
  • PN Series
    PN Series
    The PN is SV Microwave’s precision version of the type N which offers the user superior electrical characteristics. This series is constructed in stainless steel passivated or gold plated. The PN series meets or exceeds all parameters of MIL- PRE- 39012 Type N connectors designed to this military specification.
    More
  • PTNC Series
    PTNC Series
    The PTNC connector is SV Microwave's precision version of the TNC and offers the user superior electrical characteristics. With a frequency range of DC to 15 GHz and tighter machine tolerances, the PTNC series is used in applications such as telecom, base stations, radars, and antennas. The PTNC has a threaded coupling interface, which ensures the connector will not de-couple in vibration-intensive applications.
    More
  • RF
    RF

    RF

    More
  • RF DC Block Lightning Protector
    RF DC Block Lightning Protector
    The LP-WBX-N high performance series uses a filter circuit to provide exceptional lightning protection over the 2000-6000MHz frequency band, covering both the unlicensed WiFi bands and several licensed operating bands. Unlike competitive protectors, the white bronze plated construction of the LP-WBX-N series eliminates potential galvanic corrosion issues and provides long life in hostile environments. The fully weatherized housing is sealed to IP65 allowing for outdoor as well as indoor installation.
    More
  • RF DC Pass Lightning Protection
    RF DC Pass Lightning Protection
    The Times-Protect® LP-GTV-N series is an exceptional broadband DC pass design for lightning protection applications requiring DC power to be supplied to the electronics. These devices exhibit outstanding RF performance with high surge current handling characteristics and cover a broad range of applications requiring up to 150W of RF power handling. Its fully weatherized housing meeting IP67 standard allows for outdoor as well as indoor installation. The N connector designs cover the entire frequency spectrum from DC through 7000MHz.
    More
  • Secure Locking SMP/SMPM Series
    Secure Locking SMP/SMPM Series
    SV Microwave’s QuarterBack® connector line utilizes a quarter turn bayonet style coupling nut with a locking feature for standard SMP/SMPM interfaces. These connectors are ideal for high vibration and test applications that require a large number of mating cycles.
    More
  • SilverLine XF (Extra Flex)
    SilverLine XF (Extra Flex)
    SilverLine®-XF was designed for testing delicate components such as exposed RF circuits with edge launch connectors. Thin, lightweight and flexible this coax makes handling PC boards easy yet does not compromise RF stability and isolation. Using Times' proprietary TF-4 dielectric SilverLine®-XF goes one step further, exhibiting linear phase change from 0ºC to +30ºC.
    More
  • SMA Series
    SMA Series
    SMA is an acronym for SubMiniature version A. Using a threaded interface, 50 Ohm SMA connectors are precision subminiature units that provide excellent electrical performance from DC to 26.5 GHz. These high-performance connectors are compact in size and mechanically have outstanding durability. Built in accordance with MIL-PRF-39012 and CECC 22110/111, SMA connectors can be mated with all connectors that meet these spec mating diameters regardless of manufacturer.
    More
  • SMP Connectors
    SMP Connectors
    SV Microwave offers a complete line of SMP connectors that conform to DSCC 94007, 94008 and MIL-STD-348. The SMP connector was developed to meet an industry need for a smaller high frequency compact design that incorporated ease of use and functionality. The SMP bullet is the heart of this unique design.
    More
  • SMPM Series
    SMPM Series
    SV Microwave offers a complete line of SMPM connectors.  The SMPM connector was developed to improve on the application density and operating frequency range of the SMP connector.  The SMPM connector is widely used in high density, high performance applications today.
    More
  • SMPS Series
    SMPS Series
    SV's SMPS design is capable of frequencies exceeding 100 GHz. Being 45% smaller than the SMP and 30% smaller then the SMPM, the SMPS is ideal for dense packaging in multiport applications. The SMPS also has a low interface height making it an excellent choice for board-to-board applications using a bullet design. Current configurations include male and female cable connectors, board mount, edge launch and the female bullet. The male interface is available in smooth bore for easy mating or detent for female retention. Directly compatible with the G3PO interface, the SMPS has low VSWR of 1.12 to 50 GHz for the female bullet while allowing for .010” of radial and axial misalignment. The smooth bore design will mate and demate a minimum of 500 cycles and the detent design is capable of 100 cycles minimum.
    More
  • Terminations
    Terminations
    Terminations are used to prevent an RF signal from being reflected back from the end, causing interference. SV offers a broad range of terminations in SMA, 2.92mm, 2.4mm, 1.85mm, SMP, SMPM & SMPS series.
    More
  • TNC Series
    TNC Series
    Designed as a threaded version of the BNC, the TNC series features screw threads for mating. TNC are miniature, threaded weatherproof units with a constant impedance of 50 Ohms and operate at DC to 11 GHz. As a ruggedized version of the BNC, the TNC features a threaded coupling that offers extra mating stability. TNC connectors are used in many applications including Mil-Aero, instrumentation, and cable assemblies.
    More
  • Type N Series
    Type N Series
    The Type N connector was developed to satisfy the need for a durable, weatherproof, medium-size RF connector with consistent performance through 11 GHz.
    More
  • VITA 67
    VITA 67
    SV’s unique connector retention mechanism makes assembly/disassembly a lot easier than competition. The floating SMPM coaxial contacts ensure excellent RF performance in any mating condition. These parts are also designed for side-by-side implementation with VITA 46 hardware and can be cabled to Ø.086 and smaller coaxial cable types. Rear panel interface enables quick disconnect & replacement of card, leading to a significant reduction in Mean-Time-To-Repair (MTTR) when compared to front panel interfaces. Customized configurations available for 67.3 and Commercial Off-The-Shelf (COTS) versions available for 67.1 & 67.2. Go to SV’s Product Search finder on their website to find connectors readily available in distribution.
    More
  • Wedge TNC
    Wedge TNC
    SV Microwave manufactures high performance Wedge TNC connectors that incorporate a unique tapered dielectric design. This distinctive design allows the mating connectors’ dielectrics to physically overlap which effectively minimizes air gaps and generates a longer voltage path for improved voltage breakdown. The Wedge TNC allows for outstanding passive intermodulation (PIM) performance due to the tapered dielectric design feature and the tri-alloy plated brass connector body.
    More
  • ZMA Series
    ZMA Series
    The ZMA connector is a bayonet coupling device. The unique design of this connector provides a high coupling force, which is ideal for extreme vibration applications where insufficient room is available for spring loaded blindmate panels. The ZMA is a quarter-turn coaxial connector that can be mated by hand so that special tooling is not required for proper installation. There are 8 keying arrangements are available to prevent improper mating of assemblies in blind installations. The ZMA connector is designed with electrical performance of 18 GHz, overlapping PTFE dielectrics, and rugged stainless steel body construction appropriate for military applications.
    More
  • DCWG SB Directional Coupler
    DCWG SB Directional Coupler
    The DCWG 1.2 GHz Series of high quality directional couplers have been developed to meet the rigorous requirements of MDU distribution. The solder-back design, high return loss and low insertion loss make the DCWG-SB Series ideal for any RF distribution application. Advanced PCB design assures consistent performance. The available tap values for the DCWG-SB series include: 4, 6, 9, 12, 16, 20, 24, 27, 30 dB.

    These couplers manage RF distribution over varied COAX run lengths with varied power requirements in homes, MDU’s and businesses
    More
  • Digital Directional Couplers - BDC Series
    Digital Directional Couplers - BDC Series
    The BDC digital directional coupler line has led the broadband / CATV in quality and design for over a decade. Weather sealing, environmental protection, mounting options and superior electrical RF performance quickly made the BDC series the industry standard for Broadband Directional Couplers. Available in a multitude of configurations, losses and housing styles.
    More
  • Digital Splitter - BDS102H
    Digital Splitter - BDS102H
    The BDS102H digital splitter line has led the broadband / CATV in quality and design for over a decade. Weather sealing, environmental protection, mounting options and superior electrical RF performance quickly made the BDS100 series the industry standard for Broadband Splitters.
    More
  • DOCSIS Passive
    DOCSIS Passive
    The DOCSIS Passive is the next generation home networking gateway device allowing 100% passive broadband installation with nearly unlimited outlet potential. A preferred alternative to active in the home, this device can accommodate multiple STB's and MoCA Controllers without power supplies or signal amplification. This technology reduces installation costs, dramatically improves reliability and increases system performance by eliminating noise, ingress and egress.
    More
  • Drop Cable
    Drop Cable
    A premier manufacturer of drop coaxial cables since 1948. Series 59, 6, and 11 products are used throughout the premises in today’s HFC networks. These products meet all industry standards, including ANSI / SCTE 74 2003, Specification for Braided 75 Ohm Flexible Coaxial Drop Cables. Available for indoor-premise, general purpose, aerial self-support, and burial applications. Times Fiber Communications’ innovations have improved the quality and reliability of the installation, therefore improving customer satisfaction. All TFC drop products are UV stable and resistant to extreme temperature variations. Do not trust the last portion of the last mile to any other cable but TFC's.
    More
  • Fixed Length Cable Assemblies
    Fixed Length Cable Assemblies
    Amphenol RF offers a full line of pre-assembled, fixed-length cable assemblies. Fixed length assemblies are offered in all of our most popular connector series and are available in over 1400 standard configurations and lengths.
    More
  • F-Type Product Series
    F-Type Product Series
    The F-Type connector series is a high performance, cost competitive threaded connector series. Primary applications of the F-Type connectors are for cable television (CATV), set-top boxes and cable modems.
    More
  • G-PF-59 Precision Push-On F-Adaptor
    G-PF-59 Precision Push-On F-Adaptor
    The G-PF-59 is a lab-grade, high-performance push-on F-connector adapter. The G-PF-59 has been specifically designed for high-volume testing environments demanding production efficiency, durability and reliability. This adapter utilizes precision specifications, and a special high-cycle, low-tension ground spring, allowing for low insertion force and high volume testing throughput. The G-PF-59 is particularly volume effective with high-density adapter fixtures. In addition, a high-strength center conductor is used to ensure high-cycle life expectancy.
    More
  • G-Type Product Series
    G-Type Product Series
    The G-Type product series are a 75 Ω series with performance up to 1 GHz. It is ideal for cable television (CATV), set top boxes and cable modems.
    More
  • Hardline Cable
    Hardline Cable
    A premier manufacturer for coaxial cables for the telecommunications industries. Our product profile provides designs for specialized applications needing single coaxial and multi-coaxial cables in various sizes, combinations, and specifications for telecommunications as well as the radio, video, TV and information industries.

    The T10-TX10 Hardline cable line is a seamless extruded tube. TFC’s T10-TX10 cable will outlast the standard welded tube cables. This cable is designed to eliminate pinhole leaks and microcracking. This cable line can be used with all the coring tools and connectors
    More
  • HFS-x & HFS-xD Splitters
    HFS-x & HFS-xD Splitters
    Broadband Satellite Splitters
    The HFS Series broadband splitters are an advanced design providing the lowest insertion loss from 5-2150 MHz while maintaining high isolation. The HFS-2 / HFS-4 power pass to one port and the HFS-2P / HFS-4P pass power to all ports.

    The HFS-*D series high-frequency splitters have been designed with diode steered circuitry, which allows the DC power to pass from any output port to the input port and prevents DC backfeeding.
    More
  • IPA1000 Series Premises Amplifier
    IPA1000 Series Premises Amplifier
    Welcome to the IPA1000 series premises amplifier, the one that started the revolution. The first of its kind to provide an integrated solution with passive and active ports, this device drove the "Home Run" installation standard practiced by nearly every CATV operator in the United States. For over a decade, this premies amplifier has lead the industry in quality, features and cost, becoming a staple of the broadband industry.
    More
  • MCX Product Series
    MCX Product Series
    The MCX (Micro Coaxial) series is a great option where weight and physical space are limited. The MCX provides broadband capability through 6 GHz in a snap-on connector design. A range of connectors are available, including printed circuit board and cable connectors. Typical applications include automotive, wireless LAN, broadband and wireless infrastructure markets. MCX connectors conform to the European CECC 22000 spec.
    More
  • Mini-SMB Product Series
    Mini-SMB Product Series
    Amphenol's Mini-SMB 75 Ohm product series provides broadband capability through 2 GHz. Its snap-on design offers a quick connect/disconnect and utilizes die cast components in non-critical areas to provide a low-cost solution.
    More
  • Mini-UHF Product Series
    Mini-UHF Product Series
    Mini-UHF is a miniature version of the UHF connectors that were developed for use in the radio industry. Mini-UHF connectors are designed as coaxial interconnects for applications where size, weight, and cost factors are critical. With a miniature 3/8-24 thread size, these connectors provide excellent RF performance for applications up to 2.5 GHz. Mini-UHF connectors terminate to RG-58, RG-58A, RG-58B, RG-58C, and Belden 9258 cables. Crimp-type cable plugs and jacks are available as well as panel and PCB receptacles.
    More
  • MMCX Product Series
    MMCX Product Series
    The MMCX (Micro-Miniature Coaxial) product series is a micro-miniature version of the MCX. It has the all features of the MCX series, including 50 Ω impedance with a broadband capability of DC to 6 GHz and secure, fast and easy snap-on/ snap-off coupling, and a wide range of available connectors. However, MMCX connectors have a smaller footprint than the MCX series.

    MMCX is a micro-miniature connector series with a fast and easy snap-lock mechanism allowing for 360-degree rotation. MMCX connectors conform to the European CECC 22000 specification. These 50 Ω connectors offer all of the same features of theMCX series with broadband capability of DC to 6 GHz. A range of connectors is available including surface mount, edge card, and cable connectors. Common applications include broadband, instrumentation and telecommunications.
    More
  • MoCA Amplifier
    MoCA Amplifier
    The IPA2000 Series MoCA Amplifiers are designed to maximize the MoCA frequencies within the premises while optimizing the RF band simultaneously. Completely redesigned with innovate features such as Data Stabilization, CrossTalk, and DataComm, the IPA2000 series has become the new standard in CATV amplification.

    This IPA2008DSL-RSVF has 8 active outputs and 1 passive data port.
    More
  • MoCA Filter POE-F201C
    MoCA Filter POE-F201C
    The POE-F201C MoCA filter combines superior surge protection in a compact housing to be utilized a the point of entry or beyond legacy equipment in the home. Not only does the POE-F201C come in an in-line barrel housing, this MoCA filter can be integrated into nearly every premises device in the ABS product line including ground blocks, splitters, amplifiers, and gateway devices.
    More
  • Protective Caps - RF
    Protective Caps - RF
    Protective caps are available for many of our products, with options for chains and mounting hardware.
    More
  • QMA Product Series
    QMA Product Series
    The QMA is a quick disconnect version of the SMA connector. The electrical performance of the QMA includes low loss RF performance up to 18 GHz. The QMA connector offers the same high power handling capability as the SMA connector it is based on.
    More
  • QN Connectors
    QN Connectors
    Amphenol RF’s QN connector is a quick disconnect version of the N-Type connector with similar internal construction, which enables fast and easy matings with minimum space requirements. The snap-on interface makes the QN connector 10 times faster than a threaded connector. Common applications include base atations and cable assemblies.
    More
  • Semiflex Trunk & Distribution Cable
    Semiflex Trunk & Distribution Cable
    The low D.C. loop resistance of T10 and TX10 cable results in lower installation and annual power costs. These cables are ideal for urban and coastal environments, feeder or underground applications, and resistant to extensive mechanical abuse and rodent attack. These cables have a specified 1 Ghz bandwidth for all rebuilds, upgrades, or new plants, and allows a system to handle future demands.
    More
  • ShieldX® Coaxial Drop Cable
    ShieldX® Coaxial Drop Cable
    ShieldX® coax cable solution, helps solve shielding issues by providing a TriShield cable with enhanced shielding offering the following benefits:
    • QuadShield Performance in a TriShield Design
    • Technician Friendly Prep Utilizing the QuickPrep Bonded Foil Design Adopted as an Industry Standard
    • Enhanced Transfer Impedance Prior to Flexure
    • Improved Screening Attenuation Performance Prior to Flexure
    More
  • SMB Product Series
    SMB Product Series
    Developed in the 1960's, the SMB (sub-miniature) interface features a snap-on coupling mechanism and is available in 50 Ohm and 75 Ohm configurations. SMB products offer broadband performance with low reflection DC to 10 GHz and utilize die cast components on non-critical areas to provide a low-cost solution. Amphenol RF's SMB connectors conform to the requirements of MIL-C-39012, and the interface is in compliance with MIL-STD-348.
    More
  • SMC Product Series
    SMC Product Series
    The SMC interface features threaded coupling with 10-32 threads and is available in 50 and 75 Ohm configurations. SMC connectors offer broadband performance with low reflection DC to 10 GHz and are primarily used in telecommunications and instrumentation applications.
    More
  • SMZ Connectors
    SMZ Connectors
    SMZ connectors feature the 75 Ohm impedance and are ideal for instrumentation applications.
    More
  • Tech Bag 2
    Tech Bag 2
    The Tech Service Bag II for broadband and CATV installers. Designed with an array of features, the Tech Service Bag II is also environmentally friendly using a reusable reel and flange, eliminating cardboard and plastic waste. It’s sturdy and water resistant body features a reinforced bottom capable of maintaining it’s shape and performing as a true technician assistant. Capable of holding a 500 ft reel on plastic flange, the coil can be changed quickly and easily. Cable reels pay off with an easy and fluid feel due to the unique side support design system preventing cable tangle, jams and reel lock. Built in pouches are great for extra storage to hold tools, connectors and even includes a padded slot for an iPad or tablet. The TFC Tech Service Bag II is designed for the active cable technician by eliminating extra trips to the truck, creating accurate drop lengths, eliminating waste and providing a comfortable accessory to carry tools and equipment.
    More
  • TNC Product Series
    TNC Product Series
    Developed in the late 1950s, the TNC stands for Threaded Neill Concelman and is named after Amphenol engineer Carl Concelman. Designed as a threaded version of the BNC, the TNC connector series features screw threads for mating. TNC connectors are miniature, threaded weatherproof series with a constant 50 Ω impedance and a frequency range of DC - 11 GHz. There are two types of TNC connectors: Standard and Reverse Polarity.
    More
  • UHF Product Series
    UHF Product Series
    Originally intended for use as a video connector in radar applications, UHF coaxial connectors are general purpose units developed for use in low-frequency systems from 0.6 - 300 MHz.
    More
  • Universal MCV Compression Connectors
    Universal MCV Compression Connectors
    MCV™ Series 59 & 6 Connectors
    Holland Electronic’s new universal compression connectors were created with the commercial AV installers’ needs in mind. This series consists of five Universal Connectors that terminate most major brands of cable, including Plenum RG-6, RG-6, RG-59, Mini-23 AWG and Mini 25 AWG cables.

    FITS MOST MAJOR COAXIAL CABLE BRANDS
    Plenum RG-6, RG-6, RG-59, Mini 23 & Mini 25 - Our new MCV Universal Compression Connectors fit a wide variety of coaxial cables that vary in size between manufacturers. Some differences often include thickness of jacket or diameter of insulation depending on variance in materials used in the cable manufacturing process.
    More
  • RF cable assembly MHC-261
    RF cable assembly MHC-261
    RF cable assembly MHC-261
    More
  • RF cable assembly MHC-271
    RF cable assembly MHC-271
    RF cable assembly MHC-271
    More
  • RF Jumper & Socket
    RF Jumper & Socket
    Amphenol’s RF Jumper and Socket covers 1st through 5th generations. The 4th generation RF jumper cable is compatible with lpex spec using a soldering connection instead of crimping between RF connector and the jumper cable creating a more secure joint for better high frequency performance.
    The 5th generation version is Hirose compatible, and has a 1.0 mm mating height with 0.81 mm diameter cable. For high volume production, Amphenol provides fully automated manufacturing processes for both receptacle and jumper.
    More
  • MilTech®
    MilTech®
    Times Microwave produces sealed, flexible RF and microwave transmission line assemblies optimized for military environments. These cables exhibit an extremely long life in the rigorous environments found in airborne, shipboard and ground based applications. MilTech® cables are hermetically sealed and incorporate intermediate sections compatible with an assortment of connector systems.
    More
  • RF receptacle connector MHC-260
    RF receptacle connector MHC-260
    623-26000-69212
    More
  • RF receptacle connector MHC-270
    RF receptacle connector MHC-270
    653-27000-1000
    More
  • RF Switches
    RF Switches
    Amphenol’s full range of RF switches come in straight and right angle mountings as well as miniature, low-profile, and lightweight versions for different phone design requirements. Our full mechanical switches provide high reliability for wireless terminal testing and connection to external car antennas of up to 5Ghz.
    More
  • FAKRA Product Series
    FAKRA Product Series
    FAKRA products are embedded within a plastic housing which features multiple color codes for easy identification and unique keying to prevent mismating, FAKRA connectors are designed to perform up to 3 GHz and meet the particular mechanical and environmental requirements of the automotive industry.
    More
  • HSD Connectors
    HSD Connectors
    HSD interconnect products focus on various application areas in the automobile, such as the inside compartment for connections to displays, head units and rear seat infotainment modules.
    More
  • LMR® Cable
    LMR® Cable
    LMR cables are high performance coaxial communications cables designed for use in virtually all wireless system applications. The cables are more flexible than corrugated cables and exhibit much lower loss than traditional RG cables. Additional LMR products include high performance connectors in popular interfaces, prep tools, installation tools and accessories.
    More
  • LMR® Cable Installation Tools
    LMR® Cable Installation Tools
    Times Microwave Systems offers a complete line of rugged, specially designed custom cable prep tools. These tools are designed to eliminate or minimize many of the mechanical and electrical variables that play a part in the connector attachment process. In addition to providing much desired control in the field connector attachment process, they offer a considerable time savings and are much safer to use than traditional cable prepping.
    More
  • LMR® EZ Style Connectors
    LMR® EZ Style Connectors
    Times Microwave is the leader in providing high quality EZ style connectors. These non-solder type connectors use silver or gold plated beryllium copper spring contacts for optimal cable contact and offer considerable time savings, increased performance and more reliability than traditional solder-pin connectors. Most of our EZ connectors are available in an "X" version - no braid trim required.
    More
  • 4.3/10 Product Series
    4.3/10 Product Series
    Amphenol RF offers a full range of 4.3-10 connectors and adapters, which are engineered for the wireless market and are ideal for applications requiring low passive intermodulation, or PIM.
    More
  • 7/16 Product Series
    7/16 Product Series
    The 7/16 series provides superior performance for both return loss and intermodulation distortion (IMD). These connectors are very robust, extremely stable and mostly with waterproof specifications, making them ideal for applications where vibration resistance and environmental protection is important.
    More
  • AMC Product Series
    AMC Product Series
    The AMC series has a low profile (2.5 mm off the board) and offers an extremely small board footprint (3 mm x 3 mm).Their snap-on interface performs superbly under shock and vibration conditions, making them ideal for wireless handheld devices. This series is used in applications with 50 Ω impedance requirements and has a performance from DC to 6 GHz. Amphenol RF's AMC cable assemblies are ideal for space-constrained board-to-board connections in small devices.
    More
  • AMMC Product Series
    AMMC Product Series
    The AMMC (Amphenol Micro-Miniature Coaxial) connector series is a low profile (1.4 mm of the board) series with an extremely small board footprint (2mm x 2mm). This series is used in applications with 50 Ω impedance requirements and has a performance from DC to 6 GHz. The coupling style of the AMMC connector series is snap-on for secure and easy mating.
    More
  • Between Series Adapters
    Between Series Adapters
    Amphenol RF's between series adapters are 2-port interconnects that provide a mechanical conversion between two RF connector types. They are available across many connector series and in a variety of orientations and mounting types.
    More
  • Coaxial Fixed Attenuators
    Coaxial Fixed Attenuators
    Amphenol RF attenuators are designed to offer flat attenuation over the designated frequency range and feature a microwave grade resistor that consistently reduces power. Hex flats on the body allow this attenuator to be easily torqued to the mating connector.
    More
  • Coaxial IPTV Splitters
    Coaxial IPTV Splitters
    GHPNA Coaxial IPTV Splitters
    Holland's GHPNA splitters have been specifically designed to work in HPNA environments. The low port-to-port isolation allows HPNA communication signals to pass through the splitters to set top boxes with as little signal loss as possible. At the same time the GHPNA Series splitters provide good return loss and
    More
  • Coaxial Terminators and Loads
    Coaxial Terminators and Loads
    Amphenol RF terminators are available in many common series and genders including 1.0/2.3, APC-3.5, APC-5. 5, BNC, F-type, HD-BNC, N-Type, QMA, and SMA. Amphenol RF terminators reliably prevent RF signals from being reflected along the transmission line to reduce interference.
    More
  • Connector- QC2 F connector
    Connector- QC2 F connector
    The QC II F-Connector is a universal compression connector that is ideally suited for professional and consumer use. The simple to use one-piece design provides a secure 360 degree compression seal resulting in maximum RF shielding performance. The all metal design of the connector body and nut allow for unparalleled electrical and mechanical performance. The detachably coupled advanced polymer compression system is pre-positioned to ensure a consistent fit with the cable and is color coded to allow differentiation between different cable series.
    More
  • CPI-WHP Isolator & Surge Protector
    CPI-WHP Isolator & Surge Protector
    Amphenol offers a full line of CATV isolators and surge protectors.

    The CPI-WHP is an IEC Class Level 5 isolator offering the surge protection performance necessary to ensure the highest telecom equipment survivability. The device protects cable modems, STB's and other CPE and plant equipment from damage due to fast transients and spikes from electrical storms and power surges.

    High winds, thunder, rain showers and flooding are commonplace in regions with high electrical storm activity. The CPI-WHP is rated to IP67 standards for protection against wind-blown objects and moisture - up to full submersion in a meter’s depth of water.
    More
  • Crimp Tools
    Crimp Tools
    Amphenol RF offers a full line of termination tooling to meet your specific production requirements. All tools meet Amphenol’s stringent design and quality requirements and provide a consistent and reliable crimp each and every time, thereby ensuring the integrity of the connector termination.
    More
  • N-Type Product Series
    N-Type Product Series
    N-Type connectors, adapters, and cable assemblies are designed to satisfy the need for a durable, weatherproof, medium-size RF products with consistent performance through 11 GHz. Our N-Type connecters feature threaded coupling mechanisms and are fully interchangeable with N-Type connectors made to the MIL-C-39012 specification. These connectors are used in all systems where excellent RF and mechanical performance is critical.
    More
  • PhaseTrack®
    PhaseTrack®
    PhaseTrack® cable assemblies are designed for applications demanding minimal phase change over temperature. All PhaseTrack cables use proprietary TF4® dielectric that does not have the abrupt shift in the phase that occurs with solid or tape wrapped PTFE based products under normal room ambient temperature conditions. PhaseTrack cable has the same triple shield construction used in Times popular SF®, SFT®, SilverLine® and MT cables.
    More
  • RF Combiners
    RF Combiners
    Amphenol Private Networks' product programme of VHF & UHF RF combiners allow multiple transcievers to be connected together through one antenna system. Traditional designs are combined with state-of-the-art technologies to produce world leading products, including:
    Cavity Combiners
    Hybrid Combiners
    Single-Tray Combining Solutions
    Active Reciever Multicouplers
    More
  • RF Filters
    RF Filters
    Amphenol Private Networks' product programme of VHF & UHF RF Filters provide high-quality RF signal conditioning for professional applications. Products are available for frequencies between 27MHz and 5. 8GHz, including:
    High Pass and Low Pass Filters
    Duplex Filters
    Diplexers and Triplexers
    Band Pass / Band Reject Filters
    More
  • SFT™
    SFT™
    SFT™ high performance microwave cables are rugged and flexible making them ideal for interconnect applications from inside LRUs to system interconnects and antenna feeders in military and commercial systems. The wide range of available connectors cover many interface types and frequency ranges.
    More
Contact Form
Send
